Colin 960P Outdoor Onvif IP Camera H.264 1.3Megapixel HD Waterproof IP66 anpr camera
IP CameraFeature:
Technology optional: White light or Infrared IR
1.Built-in 6pcs high quality IR/White LED F25mm array led special from taiwang factory
2.Day/night color Night vision Distance 40-60m
3.Using high quality oversea mega2 pixel big iris fixed lens: 4/6/8/12/16mm
4.Super night vision technology II (SNVII) support
5.Good performance alloy housing, good for heat emission
6.Depart LED, antifogging and anti-reflection
7.waterproof and sunproof design for outdoor using
8.New design housing, very good for imprvoing
IP CameraFunction:
1. H.264 video compression standard
2.Embedded Web Server, Comprehensive support Internet Explore Surveillance, of Internet Explore to monitor, setup and updating.
3.Two-way audio transmission on the Internet (Function optional) video frame rate automatically adjust according to the Internet bandwidth
4.Support variable bit-rate, when setting the video image quality, and also can limit the compressed stream of video images
5. Support SLD(second-level domain), easy to implement dynamic IP address (ADSL, dial-up)
6. Support Video bit rate (50 Kbps - 8 Mbps ) continuously adjustable, frame rate [1-30 (1-25) ] continuously adjustable
7. Support video capture and record the video
8. Dynamic detection (Can setting area and sensitivity )
9. Support client monitoring, resolution 1280 * 720/1280 * 960/1280 * 1024/1600 * 1200/1920 * 1080/2048 * 1536,
customers can adjust the settings , remote / local monitoring, remote / local realtime video, realtime screenshots.
10. Support multiple record video mode and also cycle record the video.
11.Support IO interface connect to the other peripherals
12.Support 10/100M Ethernet interface
13.Alarm pre-recording function (Function optional)
14.Support multiple network protocols: HTTP, TCP/IP , UDP , SMTP , The TCP / IP, UDP,
SMTP, DDNS , DDNS, DNS , SNTP , DHCP , FTP , DNS, SNTP, DHCP, FTP, SNMP SNMP RTSP RTSP
15.Video image motion detection, real-time manual recording, video file playback system
16.RS485 interface, support multiple PTZ protocols, control PTZ and electronic Zoom lens
by the client software from remote control (optional function)
17.Abnormal condition auto-recovery feature, network interrupt conditionauto-connect feature
18.One-way/two-way voice feature (optional function)
19.Application area: Home safe, businesses, communities, transportation, finance security and other fields
IP CameraTechnical parameters:
| Model | CL-866NHILD/CR | |||
| Feature | 960P1.3Mega waterproofIP Camera |
|||
| Camera and lens | Image Sensor | 1/3" Aptina AR0130 Low illumination 1.3Megapixel CMOS | ||
| Minimum Illumination | 0.05Lux (or NO) | |||
| Electronic shutter | Automatic | |||
| Lens Mount Type | CS Oversea big iris lens | |||
| Lens focal length | 4mm, 6mm, 8mm, 12mm, 16mm optional | |||
|
Compression standard |
Video compression standard | H.264 | ||
| Video compression code rate | 300Kbit / S ~ 8Mbit / S | |||
| Audio compression standard | G, .711 | |||
| Image | Exposure mode | Auto exposure, auto white balance, automatic gain | ||
| Video Resolution | 1280×720(25fps) 1280*960(25fps) 1920*1080(18fps) | |||
| Frame rate | 1-30 frames / sec. | |||
| Playback frame rate | 1280×720(25fps) 1280*960(25fps) 1920*1080(18fps) | |||
| Pixels wide dynamic range | 69DB | |||
| Image Settings | Saturation, brightness, contrast adjust by the client or IE browser | |||
| Network functions | Remote browsing | Support 320X192, 640X360 real-time remote browsing and control | ||
| Remote reset and upgrade | Through a network remote to reset the system and updating firmware | |||
| Support Agreement | RTSP,TCP,UDP,IP,HTTP,FTP,SMTP,DHCP,DNS,ICMP | |||
| Common functions | One-key reset, anti-flash, dual-stream, password protection, built-in watchdog | |||
| Interface | Communication interface | One RJ45 10M/100M Ethernet port, one RS-485 interface(optional function) | ||
| Audio input / output | 1 channel (optional) | |||
| Alarm Input / Output | 1 channel(optional) | |||
| D1 analog video output | BNC connectors output (optional) | |||
| Other parameters | Day and night switch | IR-CUT filter switch(only for the Infrared mega ip camera, white light mega Camera ip are the color filter) | ||
| Power input | DC 12V 2A | |||
| Led Lamp |
Using High quality Powerful No.4 Array white LED (long distance, Long Life) |
|||
| Waterproof Grade | IP66 | |||
| Operating Temperature | -10 °C ~ 70 °C | |||
| Operating Humidity | Less than 90% (no condensation) |
|||
IP Camerasoftware to surveillance and control:
IP Camera effect adopt white Light Technology
White Light Technology Perfect apply for IP Camera
If you want to know more information about our products welcome to contact us in any time, And welcome to our company! We display more our camera effect quality in our showroom.
------------------------------------------------------------------------
Top 10 China CCTVWifi IP Cameramanufacturer
White light CCTV Camera the sales No.1 in the world!
1. Any inquiries will be replies within 24 hours
2. Professional manufacturer. welcome to visit our website or factory:
3.OEM/ODM available:
1).Silk print logo on theWifi IP Camera;
2). CustomizedWifi IP Camerahousing;
3). Customized ColorWifi IP CameraBox;
4).Any your idea onWifi IP Camerawe can help you to design and put it into production.
4. High quality,fashion Designs, reasonable &Competitive price, fast lead time.
5.After-sale Service:
1). All products will have been strictly Quality checked in house before packing;
2). All products will be well packed before shipping;
3). All our products have 2 years warranty, and we sure the product will be free from maintenance within warranty period;
4). if quanity more than 100pcs one model, we will free supply some Mega camera IP parts for preapre exchange
6. faster delivery time: Samples, 2-3 days, 10-1000pcs 3-5 working days.
7.Shipping
We have strong cooperation with DH, TNT,UPS,Fedex,EMS,Air shipping or Ocean shipping;
You also can choosing your own shipping forwarder.
1.Free Reback during one month.
2.Free exchange during three month.
3.Free repaired during two years ( warranty excludes accident, human fault or improper use).
4.Faster delivery time with good after-sale services waitting the long term cooperation.
Q.May I print our company logo on package box andWifi IP Cameraand NVR?
A:Of course,buyer logo is welcome in our company.We have one production line for printing buyer logo.
Q.Do you provide warranty for your products?
A:Yes,we promise two years warranty for all our products.
Q.What is your method of payment?
A:Pay via T/T,Western Union,Escrow, paypal and so on; L/C is welcome.
Q.What is Minimum Order Quantity?
A:Minimm Order Quantity is 50pcs,but sample order is welcome.
Q.What is Carton box quantity?
A: Big carton box size: 74*39*56cm max quantity: 20pcs
