Colin 800tvl outdoor waterproof ir camera gsm based alarm system

Specifications

gsm based alarm system
100% manufactruer for cctv
5 Years Golden Supplier in alibaba
White light technology support
CE FCC



CCTV camera Feature

Technology support choosing: IR or white light Technology

1.Super night vision technology II (SNV II)
2.Built-in 2pcs No.3 high quality arrya led lamp special from Taiwan

3. Real color night vision distance: 10-30m

4. Adopot Oversea big iris small fixed lens: 3.6/6mm
5.Depart led, antifogging and anti-reflection!
6.Waterproof and sunproof design for outdoor application
7.New patent design high class for waterproof and heat emission
8.Original sony/panasonic ccd chip or Color aptina CMOS chip optional
9.long time warranty to ensure the white light cctv camera quality











MODEL	CL-F40KD/R	CL-F40ED/R	CL-F40A7D/R	CL-F40A8D/R	CL-F40E8D/R
TV System	PAL/NTSC
Pixel	PAL:500(H)X582(V)	PAL:976(H)X582(V)	PAL:720(H) X576(V)	PAL:720(H) X576(V)	PAL: 976(H) x 582(V)
	NTSC:510(H)X494(V)	NTSC:976(H)X494(V)	NTSC:720(H)X487(V)	NTSC:720(H) X487(V)	NTSC: 976(H) x 494(V)
Pickup device	1/3"SONY Super HAD CCD II	1/3"Sony Exview CCD  +effio-e DSP	1/4" ADS Pixel Color CMOS		1/3" PANASONIC CCD+ Color DSP
Scanning area	4.8mm(H)*3.6mm(V)		3.6mm(H)*2.7mm(V)		4.8mm(H)*3.6mm(V)
Horizontal resolution	480TVL	700TVL	700TVL	800TVL	800TVL
Minimum illumination	0 LUX(IR ON)
S/N ratio	>48dB
Gamma  characteristic	0.45
Electronic shutter	PAL:1/50~1/100000sec
	NTSC:1/60~1/100000sec
Gain control	Auto
Back light  compensation	Auto
White balance	Auto
Synchronous system	Internal synchronization
Operating temperature	–20~50°C
Protecion rate	IP66
Lens mount	oversea big fixed iris lens: 4/6/8/12/16 (Optional)
Power in	DC12V 2A
Video out	1.0Vp-p/75Ω(BNC)
Dimensions(mm)	200(L)*95(W)*70(H)
Weight(g)	620g



Recommend New cctv camera technology: White light technology

Better than general IR CCTV Camera



No Color Deviation during Daytime

 Color is Brighter and  More Realistic Effect





Real Colorful Image in the Nighttime

Colin's White Light Technology Increase the Colorful Imformatioin during the Nighttime,It illuminates the Darkness and Render a Daylight Effect, Therefore Aiding Face Recongnition and Profiling during Investigation





Lower Power, Longer Service Life, More Energy Efficient, More Enviromental Protection

The 'White Light' Led ONLY Use 60% Power Compared to the IR Camera's 80% Power Consumption, Which will Protect the Camera and Performs More Stability. White Light Cameras not only Help Users Save Energy,It also Protects Our Enviroment Due to Its Lower Carbon Emission.COLIN Promots this Energy Efficient Products



Illumination and Warning Function at Night

Colin's White Light Camera Uses High Quality Eviromental Protection White Light Led from Taiwan.At Night It can be Used as "Street Lamp" and "Security Light" at the Same Time. This Function helps Ward Off Potential Burglas, Keeping Your serveillance Places Safe at Night.



illumination Protection, Anti-Static

Comprehensive Protecting the Camera Power Input and Signal Output.Using High Class Proctective Circut Design Help Camera Complete Eradicate the Hazards of Illumination and Stactic





Super Night Vision Ehance Technology II(SNVII)

We Improved the Function of Absorbing more Reflection Light by Using Higher Illumination Effecient Led Diodes. Using Oversea Big Oris Lens and Improved Back-End Circuity to Ehnhance Brightness during Dark Enviroment. Enhancing more of the Night Vision





Colin's Camera Effect---White Light cctv Camera daytime and nighttime image:







1. Any inquiries will be replies within 24 hours
2. Professional manufacturer. welcome to visit our website or factory:
3.OEM/ODM available:
1).Silk print logo on the white light cctv camera ;
2). Customized White light cctv camera housing;
3). Customized Color Box;
4).Any your idea white light cctv camera we can help you to design and put it into production.
4. High quality,fashion Designs, reasonable &Competitive price, fast lead time.
5.After-sale Service:
1). All products will have been strictly Quality checked in house before packing;
2). All products will be well packed before shipping;
3). All our products have 3 years warranty, and we sure the product will be free from maintenance within warranty period;
4). if quanity more than 100pcs one model, we will free supply some white light cctv camera parts for preapre exchange
6. faster delivery time: Samples, 2-3 days, 10-1000pcs 3-5 working days.
7.Shipping
We have strong cooperation with DH, TNT,UPS,Fedex,EMS,Air shipping or Ocean shipping;
You also can choosing your own shipping forwarder.



About US

Our company is committed to the development of the industry for many years, with advanced technology and talents. To provide customers with the most satisfactory product quality and thoughtful service. We hope to develop together with you hand in hand. I hope the majority of buyers can come visit and tour company, your satisfaction is our greatest pursuit.



Material:

High-quality aluminum alloy, white light patent New technology for cctv camera .



Function:

Compliance with international CE FCC ROHS certification, daytime no color deviation, real color night vision at Night.



Supply capacity:

Our company for many years been in this industry, with advanced equipment and technology to ensure supply the good quality products with good price and delivery ontime for you.



Packing:

Usually carton packaging  with a label. Specifically according to the customer to your needs, you can use your company Logo print in the  White light cctv camera housing or Label.





If you want to know more information about our products welcome to contact us in any time, And welcome to our company! We display more our white light cctv camera effect quality in our showroom.
------------------------------------------------------------------------
Top 10 China white light cctv camera manufacturer
White light cctv camera- the sales No.1 in the world!





Q.May I print our company logo on package box and white light cctv camera and DVR?

A:Of course,buyer logo is welcome in our company.We have one production line for printing buyer logo.

Q.Do you provide warranty for your products?

A:Yes,we promise Three years warranty for all our products.

Q.What is your method of payment?

A:Pay via T/T,Western Union,Escrow, paypal and so on; L/C is welcome.

Q.What is Minimum Order Quantity?
A:Minimm Order Quantity is 50pcs,but sample order is welcome.

Q.What is Carton box quantity?
A: Big carton box size: 67*42*65cm max quantity: 37pcs
