High quality hydraulic dock leveler/docking system
Product description
1.hydraulic dock leveler is the auxiliary equipment for cargo loading and lifting
It is widely used in warehouse ,station ,wharf ,warehousing logistics base ,postal transportation ,logistics distribution etc.
2.Convenient push button activation and first-class hydraulic technology increase the efficiency and safety of the loading /discharging jobs
3.It is classified to five kinds by carrying-weight capacity ,such as ,6T,8T,10T,12T,15T etc .
| type | load | platform size |
lip (mm) |
travel upper/ lower |
power | l | w | h |
| DCQ6-0.55 | 6000 | 2000*2000 | 400 | 300/250 | 0.75 | 2080 | 2040 | 600 |
| DCQ6-0.7 | 6000 | 2500*2000 | 400 | 400/300 | 0.75 | 2580 | 2040 | 600 |
| DCQ8-0.55 | 8000 | 2000*2000 | 400 | 300/250 | 0.75 | 2080 | 2040 | 600 |
| DCQ8-0.7 | 8000 | 2500*2000 | 400 | 400/300 | 0.75 | 2580 | 2040 | 600 |
| DCQ10-0.55 | 10000 | 2000*2000 | 400 | 300/250 | 0.75 | 2080 | 2040 | 600 |
| DCQ10-0.7 | 10000 | 2500*2000 | 400 | 400/300 | 0.75 | 2580 | 2040 | 600 |
Application
It is widely used in warehouse ,station ,wharf ,warehousing logistics base ,postal transportation ,logistics distribution etc.
Features
1.Full hydraulic drive, easy to operate, reliable operation
2.Lip connection with the long axis of the entire platform, high strength and reliability
3.Imported seals to protect the hydraulic system with excellent sealing performance
4.Imported overall modular hydraulic station, sealing, and long service life
5.High intensity "u" shaped beam design to protect its long-running high-load deformation
6.Non-slip tread plate, so that the platform has a good anti-slip properties
7.Both sides of the fortification pinches skirt, extending into the platform to prevent accidental injury toe
Details
| Packaging Details: | stander export packing |
|---|---|
| Delivery Detail: | 15 days after confirmation of the purchase order |
1)- One year warranty for whole machines.
2)- Providing free quick-wear part.
3)- Low charge for continue maintenance when warranty is expired.
4)- Exclusive engineer support at any time.
5)- We can provide free training to end-users
6)- 24hours online services
1. How about the delivery time?
Within 15 working days after we receive the order
2. What kind of payments do you support?
T/T, L/C, other kinds, pls contact with us.
3. What is the MOQ?
Generally speaking, the MOQ is 1 set, Different products have different MOQ. More quantity, better price. pls contact with us.
4. Can you produce according to customer's requirements?
Yes, of course, we are professional manufacturer, need tell us the lifting height, load capacity and platform size,
OEM we are also welcome.
5. Can you tell us your main customers?
That's our customer's privacy, we should protect their information, when you need, we ask them first, if agree, we can tell u.
At the same time, pls rest assured that your information is also safe here.
If you want to customize the products,please provide below details:
1- Lifting Capacity
2- Lifting height
3- Platform size
4- working height
5- Other special needs
Any confusing,please contact us directly.
