Specifications
1DWDM,1.25Gbps, 80km, -5~+70,With Digital Diagnostic Monitoring2SFP Transceivers for DWDM SONET/ SDH
3.CE,FCC,ect
4,1~3days
OPTFOCUS DWDM SFP Optical Transceiver
Description
OPTFOCUS DWDM SFP Transceiver exhibits excellent wavelength stability, supporting operation at 100 GHz channel , cost effective module. It is designed for DWDM SONET/ SDH, Gigabit Ethernet and Fiber-
Channel applications.
The transceiver consists of two sections: The transmitter section incorporates a colded DFB laser. And the receiver section consists of a APD photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. OPTFOCUS DWDM SFP transceiver provides an enhanced monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage, laser temperature and TEC current.
Features: |
Application: |
| Wavelength selectable to C-band and L-band ITU-T grid wavelengths Suitable for use in 100GHz channel spacing DWDM systems DWDM SFP MSA Compliant Up to 2. 667Gb/s data rate Cold Start up Wavelength Compliance Low Power Dissipation <1.3W Maximum -5ºC to 70ºC Operating Case Temperature Diagnostic Performance Monitoring of module temperature, supply Voltages, laser bias current, transmit optical power, receive optical power, Laser temperature and TEC current Extended link budget with APD receiver technology OC48/STM-16 Long Reach 80km(1600 ps/nm), 120km(2400 ps/nm) Versions RoHS compliant and lead free |
SFP Transceivers for DWDM SONET/ SDH Ethernet IEEE 802.3ae Fiber Channel |
Ordering information
Part Number Product Description
OFSD-XX12-80CD DWDM, 1.25Gbps, 80km, -5ºC ~ +70ºC,With Digital Diagnostic Monitoring
OFSD-XX12-120CD DWDM, 1.25Gbps, 120km, -5ºC ~ +70ºC,With Digital Diagnostic Monitoring
OFSD-XX25-80CD DWDM, 2.5Gbps, 80km, -5ºC ~ +70ºC,With Digital Diagnostic Monitoring
OFSD-XX25-120CD DWDM, 2.5Gbps, 120km, -5ºC ~ +70ºC,With Digital Diagnostic Monitoring
OFSD-XXMR-120CD DWDM, Multi-rate, 120km, -5ºC ~ +70ºC,With Digital Diagnostic Monitoring
XX=17~61 (ITU Channel C-band) 62~16(ITU Channel L-band)
Dense Wavelength Division Multiplexing (DWDM) Small Form-Factor Pluggable (SFP) transceivers provide the high speeds and physical compactness that today's networks require while delivering the deployment flexibility and inventory control that network administrators demand. Our DWDM SFPs are available in all 100 GHz or 50Ghz C-band wavelengths on the DWDM ITU grid. They are designed to Multi-Source Agreement (MSA) standards to ensure broad network equipment compatibility. As multirate interfaces they support any protocol from 100 Mbps to 4.25 Gbps, for 8G/10G please see SFP+ category. The EOLS-16xx-xx transceivers are small form factor pluggable modules for bi-directional serial optical data communications such as 4x/2x/1x Fibre Channel, SDH/SONET, Ethernet applications.The modules are hot pluggable and digital diagnostic functions area vailable via an I2C serial bus specified in the SFP MSA SFF-8472. The modules meet the requirements of the IEEE802.3 Gigabit Ethernet standard and ANSI Fibre Channel specifications, and are suitable for interconnections in Gigabit Ethernet and Fibre Channel environments.
Ordering info.
P/N |
Data Rate |
Distance |
LD |
PD |
DDMI |
OFSD-xx12-80x(D) |
1.25Gbps |
80km |
cooled DFB |
APD |
Y |
OFSD-xx12-120x(D) |
1.25Gbps |
120km |
cooled DFB |
APD |
Y |
OFSD-xx24-80x(D) |
2.5Gbps |
80km |
cooled DFB |
APD |
Y |
OFSD-xx24-120x(D) |
2.5Gbps |
120km |
cooled DFB |
APD |
Y |
