Home > Products > SFP Module > 155M BIDI SFP transciver 20km
155M BIDI SFP transciver 20km
- 5000 Pair / Pairs per Month
- shenzhen
- T/T Credit Card PayPal
You May Like
-
1.25G 120km DWDM SFP Optical Transceiver With Digital Diagnostic Monitoring
-
2.5Gbps CWDM SFP 80km Optical Transceiver with duplex LC receptacle
-
155M 120km Hot-Pluggable SFP Footprint LC Optical CWDM SFP Transceiver
-
1.25G,80KM DWDM SFP Optical Transceiver With Digital Diagnostic Monitoring
-
2.5Gbps CWDM SFP 80km Optical Transceiver with duplex LC receptacle
-
2.5Gbps CWDM SFP 40km Optical Transceiver
Product Details
| Place of Origin | Guangdong, China | Brand Name | OPTFOCUS | |
| Model Number | OFSB-1303-20X |
Product Description
Specifications
SFP Optical Module1.Hot -pluggable SFP Footprint
2.ROHS DDM available
3.Compliant with cisco,Juniper,Huawei ...
BIDI SFP Transceiver
Product Feature
OPTFOCUS BIDI Fast and Gigabit Ethernet SFP is a compact optical transceiver, module used in optical communications for both telecommunication and data bidirectional communications applications.
Product Feature
l Fiber Bi-Directional SFP Optical Transceiver
l Simplex SC or LC Connector
l 1310/1550, 1490/1550, 1310/1490, 1510/1570 or other BOSA TX/RX combination is avalable on request.
l up to 160km bidi link
l AC/AC Coupling according to MSA
l RoHS Compliant
l Commercial 0 to 70C or Industrial -40 to 85C Case Operation Temperature range
l Class 1 Laser International Safety Standard IEC 60825 Compliant
Standard Application
l ATM SDH PDH SONET Network
l Data Communication Network
l Telecom Communication Network
Order Information
OFS- | A |
|
|
|
| ||||||||||||
| A | B | C | S | E | F | G |
|
|
| |||||||
Number | Parameter | Sescription | |||||||||||||||
A | ProSuct Type | S=SFP Transceiver | |||||||||||||||
B | Wavelength | 13=1310nm FP | 85=850nm VCSEL | 14=1490nm DFB |
| ||||||||||||
15=1550nm DFB | 133=1310nm DFB | 155=1550nm FP |
| ||||||||||||||
C | Sata Rate | 12=1.25G | 03=155M | 25=2.5G | 4=4.25G | 10G=10G | |||||||||||
S | Sistance | 02=2KM | 05=550M | 10=10km | 20=20KM | 120=120km | |||||||||||
E | connector | X=“L”=LC | X=S=SC |
| |||||||||||||
