Help Center10Gb/s DWDM SFP+ Transceiver 40km
Related Products
Specifications
10Gb/s DWDM SFP+ Transceiver 40km1.Hot -pluggable SFP Footprint
2.ROHS DDM available
PRODUCT FEATURES
Compliant with SFP+ MSA
Compliant to 802.3ae 10GBASE-ER
Compliant to SFP+ SFF-8431 and SFF-8432.
Hot-pluggable SFP footprint
Built-in digital diagnostic functions
Maximum Link Length of 80 km
Single power supply 3.3V
Class 1 laser product complies with EN 60825-1
Case temperature range: -5°C to 70°C.
Power dissipation < 1.5W
APPLICATIONS
l 10GBASE-ER / EW
DESCRIPTION
The OPTFOCUS ODP-XX10G-80transivers are designed to transmit and receive optical data over single mode optical fiber for link length 40km. Digital diagnostic functions are available via an I2C.This module is designed for single mode fiber and operates at a nominal wavelength of ITU Grid, C Band DWDM wavelength. It is with the SFP+ 20-pin connector to allow hot plug capability. The transmitter section uses a DWDM EML laser and is a class 1 laser compliant according to International Safety Standard IEC-60825.The receiver section uses a PIN detector and a limiting post-amplifier IC.
PRODUCT SELECTION
ODP-XX10G-80
C-band λc Wavelength Guide Pin Descriptions
Ⅰ. Absolute Maximum Ratings
Ⅱ. Electrical Characteristics (Tcase = -5 to 70°C, VCC = 3.14 to 3.46 Volts)
Notes:
Connected directly to TX data input pins. AC coupled thereafter.
Or open circuit.
Into 100 ohms differential termination.
These are unfiltered 20-80% values
Loss Of Signal is LVTTL. Logic 0 indicates normal operation; logic 1 indicates no signal detected.
