Help Center1.25G Optical Transceiver Dual Fiber 90km
Related Products
Specifications
1.25G optical transceiver dual fiber 90km LC connector1.ROHS,CE
2.DDM
3.Compliant with cisco,HUAWEI,3com,Juniper ...
1.25G SFP Double fiber
Description
The IEEE 802.3z standard includes 1000BASE-SX for transmission over multi-mode fiber, 1000BASE-LX for transmission over single-mode fiber, 100BASE-FX is a version of Fast Ethernet over optical fiber. It uses a 1300 nm near-infrared (NIR) light wavelength transmitted via two strands of optical fiber, one for receive(RX) and the other for transmit(TX), 100BASE-SX is a version of Fast Ethernet over optical fiber. It uses two strands of multi-mode optical fiber for receive and transmit. Eoptolink is produce complete range for FE and GE optical fiber transceivers.
Product Feature
l Operating Temperature :0°C-70°C or -40°C-85°C
l 1310//1490/1550nm FP or DFB LD transmission
l Transmission distance:120km max
l LC fiber interface
l Voltage:+3.3V
l Compliant with ITU-T G.957 G.958 specification
l Compliant with Telcordia(Bellcore)GR-468-CORE specification
l Compliant with RoHS specification
Standard Application
l ATM SDH PDH SONET Network
l Data Communication Network
l Telecom Communication Network
Order Information
PART NO. |
Data Rate |
Wavelength |
Distance
|
Interface |
Voltage |
LD |
Temperature |
OFSS-8512-05 |
1.25Gbps |
850nm |
0.5km |
LC |
+3.3V |
VCSEL |
-20°C-+70°C |
OFSS-8512-05D |
1.25Gbps |
850nm |
0.5km |
LC |
+3.3V |
VCSEL |
-20°C-+70°C |
OFSS-1312-10 |
1.25Gbps |
1310nm |
10km |
LC |
+3.3V |
FP |
-20°C-+70°C |
OFSS-1312-10D |
1.25Gbps |
1310nm |
10km |
LC |
+3.3V |
FP |
-20°C-+70°C |
OFSS-1312-20 |
1.25Gbps |
1310nm |
20km |
LC |
+3.3V |
FP |
-20°C-+70°C |
OFSS-1312-20D |
1.25Gbps |
1310nm |
20km |
LC |
+3.3V |
FP |
-20°C-+70°C |
OFSS-1312-40 |
1.25Gbps |
1310nm |
40km |
LC |
+3.3V |
FP |
-20°C-+70°C |
OFSS-1312-40D |
1.25Gbps |
1310nm |
40km |
LC |
+3.3V |
FP |
-20°C-+70°C |
OFSS-1512-60 |
1.25Gbps |
1550nm |
60km |
LC |
+3.3V |
DFB |
-20°C-+70°C |
OFSS-1512-60D |
1.25Gbps |
1550nm |
60km |
LC |
+3.3V |
DFB |
-20°C-+70°C |
OFSS-1512-80 |
1.25Gbps |
1550nm |
80km |
LC |
+3.3V |
DFB |
-20°C-+70°C |
OFSS-1512-80D |
1.25Gbps |
1550nm |
80km |
LC |
+3.3V |
DFB |
-20°C-+70°C |
OFSS-1512-100 |
1.25Gbps |
1550nm |
100km |
LC |
+3.3V |
DFB |
-20°C-+70°C |
OFSS-1512-100D |
1.25Gbps |
1550nm |
100km |
LC |
+3.3V |
DFB |
-20°C-+70°C |
-D:With DDMI Function(DDMI) | |||||||
