1000Base-T Copper Sfp Transceiverter

Specifications

Copper SFP

Product Description

OPTFOCUS 1000BASE-T or 10/100/1000BASE-T Autonegotiation can be installed into optical SFP slots enabling an optical Ethernet port (1000Base-X) to be converted into a copper Ethernet port

(1000Base-T) either in the field or in production. RJ45 Transceivers are compatible with Gigabit Ethernet and 1000BASE-T standards. For more information, inquire from us Application Note.

Feature

l  Support 1000BASE-T Operation in Host Systems or 10/100/1000 BASE-T operation in host systems with SGMII interface.

l  100m Reach Over UTP Cat5 Cable

l  Hot-Pluggable SFP Footprint

l  Fully Metallic Enclosure for Low EMI

l  Low Power Dissipation (1.05W Typical)

l  Compact RJ-45 Connector Assembly

l  Access to Physical Layer IC via 2-Wire Serial Bus

l  Detailed Product Information in EEPROM

l  Compliant with SFP MSA

l  Comercial or Industrial case temperature       range

l  Compliant with IEEE Std 802.3-2002

Application

l  LAN 10/100/1000Base-T

l  Gigabit Ethernet over Cat 5 Cable

l  Switch to Switch Interface

l  Router/Server Interface

Order Information
