Help CenterLow Insertion Loss FTTH Fiber Optical 1X8 PLC Splitter
Related Products
Specifications
PLC Splitter 1X8Low Insertion loss
Low PDL
High Return Loss,Uniform Power SplittingCompact Design, Wide Operating Wavelen
PLC Splitter 1X8
Features
² Low Insertion loss
² Low PDL
² High Return Loss
² Uniform Power Splitting
² Compact Design
² Wide Operating Wavelength
² Wide Operating Temperature
² Excellent Environmental & Mechanical Stability
² Qualified Under Telcordia GR-1221 and GR-1209
Applications
² FTTX (FTTP, FTTH, FTTN, FTTC)
² Passive Optical Networks (PON)
² Local Area Networks (LAN)
² CATV Systems
² Test Equipments
Performance Specifications
Item |
Unit |
Parameter |
Operating Wavelength |
nm |
1260~1650 |
Typ.Insertion Loss |
dB |
10.0 |
Max.Insertion Loss |
dB |
10.5 |
Max.Uniformity |
dB |
1.0 |
Max.TDL |
dB |
0.5 |
Max.PDL |
dB |
0.3 |
Min.Return Loss |
dB |
50 |
Min.Directivity |
dB |
50 |
Operating Temperature |
°C |
-40~+85 |
Storage Temperature |
°C |
-40~+85 |
Package Dimensions(L×W×H) |
mm |
40×4×4 |
Note:All the data above does not include connectors.
1.Order Information
PLCS-Port-Fiber Type-Package Dimension-Input--Output-Pigtail Length-Connector Type
Port |
0101=1x1, 0102=1x2, ..., 0404=4x4, ..., 0132=1x32, 0232=2x32 |
Fiber Type |
1=G652D, 2=G 657A |
Package Dimension |
A1, A2, …, F, K, U, X |
Input Fiber Type |
L=900µm Loose tube, S=2.0mm, R=3.0mm, B=250µm Ribbon Fiber, 0=Adapter |
Output Fiber Type |
L=900µm Loose tube, S=2.0mm, R=3.0mm, B=250µm Ribbon Fiber, 0=Adapter |
Pigtail Length |
05--20=0.5--2.0m, 0=Adapter, X=Others |
Connector Type |
FU=FC/UPC, FA=FC/APC, SU=SC/UPC, SA=SC/APC, ST=ST/UPC, LU=LC/UPC, LA=LC/APC, 00=None, X=Others |
