Specifications
Fiber Mechanical Splicer :Precision metallic alloy components with co-axial self centering, excellent and durable
Fiber Mechanical Splice
Mechanical Splicer provide quick and easy fiber splice in the field.
It employs the mature V-groove technology,can be widely applicable for splicing different optical cables,optical fiber splicing of floor distribution units (FDU),
splicing of the optical drop cables with the pigtails in the multimedia boxes, and repairing any damaged lines to realize firm and reliable splicing in optical fibers.
Mechanical Splicer applies to connect any single-core multimode fiber and single-core fiber
Easy and rapid to operate, safe and reliable.
Technical Parameter
Model | OFS-925B | OFS-925BP | |
For optical cable with (mm) | 0.25-0.25 | 3.1x2.0 | |
0.25-0.9 | |||
0.9-0.9 | |||
Optical fiber diameter | 125 um | ||
Coating diameter | 250 um | ||
Fastening force of naked fiber | >5N | ||
Operation time | 150 s | ||
Insert loss | Type Value < 0.1 dB | ||
Return loss | < -40dB | ||
Using temperature | -40~+75°C | ||
Tension strength | 10N | 50N | |
Features:
Precision metallic alloy components with co-axial self centering, excellent and durable
optical property.
Axially firm fitting of optical fibers, reducing any performance degradation due to loss
in the matching gel.
Uninterrupted fitting and connecting technology, hence signals are free of impact from
external force.
The naked fiber, tight buffer and pigtail, etc., can fully meet the environmental
requirements from the terminals customer.
Integrated protection of the coating to withstand harsh outdoor environment.
High success rate and easiness in installation. Realize firm and reliable splicing of fibers.
