7 port shrinkable seal,max 24 cores Splice Closure

Specifications

Easy and fast to increase and reduce FOSTs
Lay adapters suit for FTTH and easy to operrate

  OFS-FTH-505

Dome Mechanical Splitter Splice Closure



Features:

• Advanced internal structure design
• Easy to re-enter,it never requires re-entry tool kit.
• Teh closure is spacious enough for winding and storing fibers
• Fiber Optic Splice Trays(FOSTs) are designed in SLIDE-IN-LOCK and its opening angle is about 90^o
• The curved diameter meets with international standard
• Easy and fast to increase and reduce FOSTs
• Straight-through for uncutting and branching for cut
• Lay adapters suit for FTTH and easy to operate

Applications

• Suitable for bunchy fibers
• Pole-mounting,wall-mounting,hand hole-mounting
• underground and duct-mounting

OFS-FTH-505 Fiber Optic Splice Closure Datasheet



Model No.	Size (mm) HxD	Core capacity	Cable Ports (max)	Max diameter of cable (mm)	Adapter and holes of Front Panel
OFS-FTH-505	495x220	96	7	1×Ø36 6×Ø21	FC adapters:24PCS
					SC adapters:24PCS
					ST adapters:24PCS
					LC adapters:24PCS



Remarks:

1. OFS-FTH-505 accommodates one set of elastic seal fitting for 7 inlet/outlet ports.
2. Installation accessories provided: 1pc of special wrench, abrasive cloth, earthing wire, nylon ties, labeling paper, measuring paper, desiccant, aluminium-foil paper.

Accessories by customers’ selection: earthing device, buffer pipe, pressure testing valve, adapter panel, adapter, pigtail, patchcord, wall-mounting bracket and pole mounting
