CCTV Surveillance Camera UTP Video Surge Balun FS-SP3001UV

Name: CCTV Surveillance Camera UTP Video Surge Balun FS-SP3001UV
Brand: folksafe
SKU: 107909159
Availability: InStock

Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

folksafe

Model Number:

FS-SP3001UV

Shenzhen Folksafe Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name folksafe

Model Number FS-SP3001UV

Specifications

1.CCTV Surivenlance Camera UTP Video Surge Protector
2.can be worked as transmitter or receiver
3.balun distance:400m

CCTV Surivenlance Camera UTP Video Surge Protector

Description:

Model	FS-SP3001UV
Product Name	UTP Video Surge Protector BNC connector
Function	UTP Video Signal Surge Protection
Applied devices	CCTV/CATV system, Antenna of Television, FM receivers, video camera, monitors, multiplexers & Quad processor, VCR. VOD….etc.
Connector	BNC male and female
Nominal Operating Voltage (Un)	6V
Max Continuous Running Voltage (Uc)	8V
Nominal Discharge Current In (8/20us)}	5KA
Max Discharge Current Imax (8/20us)	10KA
Rated Load Current ( IL)	500mA
Limited Voltage	15V
Response Time	≤1ns
Max Transmission Rate	10Mbps
Matched Impedance	75Ω
Insertion Loss	<0.2dB
Housing	Aluminum alloy
Net weight	0.08kg
Dimension	582525mm
