Specifications
OFS-SCV-01-D21.Dome Shrinkable Seal Splice Closure
2.4 port small size ,max capacity is 48core
OFS-SCV-01-D2
Dome Shrinkable Seal Splice Closure
Features:
l Easy to re-enter, it never requires re-entry tool kit.
l The strong housing provide fire resistant, waterproof and quakeproof while protecting splices during pulling, tensioning and impacting.
l Design flexibility and high reliable sealing system
l Cable sealing method: mechanical type
Applications
l It can be used in straight-through and branching application
l It can be used in aerial, underground, direct buried, Wall-mounting, hand hole and duct mounting application.
l It can be mounted on a pole, wall or strand.
Model No. |
Size (mm) L×W×H |
Core capacity |
Cable Ports (max) |
Max diameter of cable (mm) |
Weight (excluding outside box) |
OFS-SCV-01-D2 |
Φ178×288 |
4 |
1*Oval: Φ20 3*Round Φ16 |
48 |
1-4 |
Accessories
The accessories included in the FOSC: earthling wire, nylon tie, emery paper, buffer tube, metal hoop, sealing tape, insulation tape, special wrench,
Accessories to be ordered in addition: earthling ground, pressure testing valve.
