Help Center24 Cores Oudoor Wall-mount Fiber Optic Distribution Frame(ODF)
Related Products
-
48 Cores Oudoor Wall-mount Fiber Optic Distribution Frame(ODF)NegotiableMOQ: 1 Piece -
48 Cores Oudoor Wall-mount Fiber Optic Distribution Frame(ODF)NegotiableMOQ: 1 Piece
-
48 Cores Oudoor Wall-mount Fiber Optic Distribution Frame(ODF)NegotiableMOQ: 1 Piece
-
24 FC Cores Fixed Rack Mounting 1U Fiber Optical Distribution Frame(ODF)NegotiableMOQ: 1 Piece
-
12 FC Cores Fixed Rack Mounting 1U Fiber Optical Distribution Frame(ODF)NegotiableMOQ: 1 Piece
Specifications
1.24cores Oudoor Wall-mount ODF2Applicable to Telecommunications,Fiber to the home (FTTH),LAN / WAN, CATV ect. System project
Oudoor Wall-mount Fiber Optic Distribution Frame(ODF)
Description
Fiber optic distribution frame provides efficient cable connections between outside plant cables and equipment inside the buildings and communications facilities.
Box integrates fiber splicing, storage and cable connections together in a unit. They can manage both bundle type and ribbon type fiber cables. It is with large working space to integrate the pigtail, cables and adapters for fiber management.
This fiber optic distribution frame is designed for outdoor wall mounted using, cold roll steel material, with adapter plate & splice tray at one side for fiber splicing, distribution and management.
Features:
Cold-roll steel, electrostatic painting
ABS plastic tray inside, 12cores per tray
Splice trays in one side or both sides available
Different adapter plate available: FC, SC, LC, ST…
Cable entry ports suitable for single fiber, bundle & ribbon fiber cables
Reasonable design ensures the cables are in good order
Wall mouted type, outdoor using, IP65; pole mounted & bottom base available
With lock on front door
12, 24, 48, 96 … capacity customised
Application:
Mainly used for cable inlet and fixing; fiber splicing and protecting; pigtail storage; patch cord storage, connection and use management between wiring closets and equipments.
Applicable to Telecommunications,
Fiber to the home (FTTH),
LAN / WAN, CATV ect. System projects.
4. Parameters:
Operating temperature: :-30~+60°C
Relative humidity: ≤85%(+30°C)
Atmospheric pressure:70~-106Kpa
Durability: >1000 times
Standard working wavelength: 850nm, 1310nm, 1550nm
4.Order Guide
Model |
Capacity |
Dimension(cm) |
Remark |
Weight |
OFS-W06A-24 |
24 cores |
465x410x110 mm |
4pcs splice trays separate in both sides |
7 |
OFS-W06A-36 |
36 cores |
460x410x155 mm |
6pcs splice trays separate in both sides |
7.8 |
OFS-W06A-48 |
48 cores |
460x410x155 mm |
8pcs splice trays separate in both sides |
7.8 |
OFS-W06A-96 |
96 cores |
500x480x210mm |
16pcs splice trays separate in both sides |
11.8 |
OFS-W06B -12 |
12 cores |
465x410x110 mm |
1pc splice tray in one side |
|
OFS-W06B -24 |
24 cores |
465x410x110 mm |
2pcs splice trays in one side |
|
OFS-W06B -48 |
48 cores |
460x410x155 mm |
4pcs splice trays in one side |
|
OFS-W06B -96 |
72 cores |
560x480x210 mm |
6pcs splice trays in one side |
|
OFS-W05B -12 |
96 cores |
560x480x265 mm |
8pcs splice trays in one side |
|
