Specifications
Adapters can be installed: FC, SC, ST, LCSuitable for single fiber and ribbon & bundle fiber cables
Indoor Wall-mount Fiber Optic Distribution Frame
Description
Indoor Wall-mount Fiber Optic Distribution Frame can manage both single fiber and ribbon & bundle fiber cables for indoor using. There are FC, LC, SC,SToutput interfaces optional, and large working space to integrate the pigtails,cables and adapters.
Features:
Cold-roll steel, electrostatic painting
ABS plastic tray inside, 12cores per tray
Splice trays in one side or both sides available
Different adapter plate available: FC, SC, LC, ST…
Cable entry ports suitable for single fiber, bundle & ribbon fiber cables
Reasonable design ensures the cables are in good order
Wall mouted type, indoor using; pole mounted available
With lock on front door
8, 12, 24, 48, 96 … capacity customised
Application:
Telecommunications subscriber loop
Fiber to the home (FTTH)
LAN/WAN
CATV
4. Parameters:
Operating temperature: -5~+40°C
Relative humidity: ≤85%(+30°C)
Atmospheric pressure:70~-106Kpa
Durability: >1000 times
Standard working wavelength: 850nm, 1310nm, 1550nm
4.Order Guide
Model |
Capacity |
Dimension(cm) |
Weight(Kg) |
|
OFS-W05A -12 |
24 |
405x380x85 mm |
4.2 |
1pc splice tray in one side |
OFS-W05A -24 |
24 |
405x380x85 mm |
4.2 |
2pcs splice trays in one side |
OFS-W05A -48 |
48 |
400x380x140 mm |
5.8 |
4pcs splice trays in one side |
OFS-W05A -96 |
96 |
560x480x265 mm |
8.5 |
8pcs splice trays in one side |
OFS-W05B -12 |
12 |
30x30x8.5 |
3 |
1pc splice tray in one side |
If you are interested in our description , then you can browse our www.optfocus .com, or call me directly (Mob: 86-15889574359)
add my skype: optfocus02
