LC SM Optic Fiber Patch Cord

LC SM Optic Fiber Patch Cord photo-1
Negotiable MOQ: 30 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Optfocus
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Optfocus

Specifications

Applications:
1)I ndoor network room wiring distribution
2)LAN, access network
3)TelecomaaGigabit data network
4)Mechaninal

LC SM Optic Fiber Patch CordLC SM Optic Fiber Patch CordLC SM Optic Fiber Patch CordLC SM Optic Fiber Patch CordLC SM Optic Fiber Patch CordLC SM Optic Fiber Patch Cord

Armed optic fiber patchcord



1,Summary

Armoured optic fiber patchcord and traditional fiber optic patchcord the biggest

difference is that it uses a small bypass pipe and a woven metal mesh to protect

the optical fiber according to fiber easy broken, easy damage defects,, and flame

retardant PVC protective sheath, in order to achieve the purpose of moistureproof

fireproof and prevention of rat bite. It can be directly laid in the network room and

other harsh environments, without the use of protective sleeves for saving space.

Armored cable structure as follows: 0.6 tightly fiber + metal hose + Dupont Kevlar

+ woven metal wire ( reinforced cable torsion function, to prevent external damage

to cable ) + environmental flame retardant PVC, than cable strength greater than the

general indoor cable. It Can prevent rat bite, compressive, tensile, meet the harsh

working environment. Greatly enhance the network maintenance convenience.



 2,Feature

Small diameter stainless steel casing pipeprotection

Against improper torsional damage

High tensile, compressive, high anti- rat bite

convenient construction, ensure the safety

No need to worry about construction, fiber damage

 3,Technical data

1)insertion loss:<=0.2db

2)return loss: >=50db(upc type),>=60db(apc type)

3)work temperature: -40°C~+80°C

4)repeatability:

5)interchangeability

6)plug times

7)tensile strength
 4,Ordering information:

product name: fiber optic patchcord/pigtail

connector type : the frist interface: FC,SC,LC,MU,MT-RJ etc; the other interface: FC,SC,LC,MU,MT-RJ etc.

interface type: the frist one: UPC,APC;the other one: UPC,APC.

Transmission mode: SM,MM.

fiber cores: single ,dual
