Common Fiber Adapter Sc/apc Adapter

Name: Common Fiber Adapter Sc/apc Adapter
Brand: Optfocus
SKU: 107906133
Availability: InStock

Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Optfocus

Model Number:

SC\LC\ST\FC

Shenzhen Optfocus Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Optfocus

Model Number SC\LC\ST\FC

Specifications

fiber adapter include Adapter , hybrid adapter and attenuator

SC adapter:
1.ISO9001:2008$ROHS Approval
2.Sell to Canada,Asian,Europe
3.Low insertion & high repeatability

SC adapter :SC/APC Simplex/Duplex adapter:

1.Features:

· Good commpatibility

· Precision-machined

· High reliability & stability

· Ceramic or Bronze Sleeve

· Two types of fiber stub:PC/UPC

· Simplex,duplex,quadruple

2.Application:

· Telecommunication Networks

· Test Equipment

· Local Area Network

· CATV

·Connecting with various types of Ferrules

3.Specifications:

SC,FC,LC,MU,MTRJ,E-2000,ST,SC/ST,FC/ST,SC/FC Fiber Optic Adapter
Parameter	Unit	Description
Insertion Loss (Typical)	dB	≤0.2
Return Loss	dB	PC≥45	UPC≥50	APC≥60
Mechanical endutance (500T)	dB	≤0.2
Exchangeability	dB	≤0.2
Operating Temperature	°C	-40~+75
Storage Temperature	°C	-40~+85
Relative Humidity	%	95

Parameter	Unit	Fixed Optical Attenuator		Variable Optical Attenuator
Operation wavelength	nm	1310,1550		1200-1600
Atteneuation Value	dB	±0.5dB(<10dB) ±1.0dB(>10dB)		0-3
Max.Optical input Power	mW	500		500
Max.PDL	dB	≤0.1		≤0.1
Retur Loss	dB	UPC	>50
Retur Loss	dB	APC	<60
Operating Temperturre	°C	-40~+75		-40~+75
Storage Temperature	°C	-40-~+85		-40~+85
