LC-ST Hybrid Adaptor

Specifications

                                                                     LC-ST hybrid adaptor
                                                         LC(Female)-ST(Female) Adapter

 Hybrid fiber optic adaptors allow users to convert from one connector type to another.

These adaptors are comprised of a polymer/metal outer body and inner assembly fitted with a precision alignment mechanism. These adaptors are precision made and manufactured to demanding specifications. The combination of a ceramic / phosphor bronze alignment sleeves and a precision moulded polymer housing provides consistent long-term mechanical and optical performance.

Features

 Female to Female hybrid adaptor

Application for system requirement

saving cost

Parameter

Excess Loss(dB) ≤ 0.20

Repeatability (dB) ≤ 0.10

Interchangeability (dB) ≤ 0.20

Material Zirconia’s

Operating Temperature(°C) -40 ~ +80

Storage Temperature (°C) -40 ~ +85
