luxury villa design log cabin homes

Specifications

Prefabricated house:
1. cost-effectiveness
2. durable structure
3. environment protection
4. easy assembly and disassembly





Advantages
Number	Item	Content
1	Low cost	Low labour and material costs
2	Long life	over 10 years
3	Recycling use	Reused for more than 10 times
4	Easy assembly	100m2house assembled by 6 workers in 2 days
5	Flexible layout	Layout adjusted according to your requirement
6	Beautiful appearance	Optional colors of panels: Ivory white, off-white, sky-blue, lotus-green, red, etc.
7	Environment protection	Environment-friendly materials used
8	Safe & Stable steel structure	Earthquake proof & Wind resistance









General Specifications of Two-Storey Slope-top Prefab House







Foshan Nanhai BoSen Building Materials Co., Ltd.
Light Steel Villa
Number	Component		Material		Specifications
A,Main Steel-structure
1	Stand column	Square steel tube			80*80mm
2	Herringbone beam	Square steel tube			80*80mm
3	Ring beam	#8 C-shaped steel			120*50*20mm
4	Roof purlin	#8 C-shaped steel			120*50*20mm
B,Wall
1	External wall panel	EPS(polystyrene) /Rock wool sandwich panel / Cement-polystyrene Panel			Thickness: 50mm/75mm/100mm
	Decorative wall panel	PVC panel / Wood plastic composite panel
2	Internal wall panel	EPS(polystyrene) /Rock wool sandwich panel / Cement-polystyrene Panel			Thickness: 50mm/75mm/100mm
C,Roof
1	Roof panel	EPS(polystyrene) /Rock wool corrugated steel sheets			Thickness: 50mm/75mm/100mm
2	Roof tile	Asphalt shingle
D,Ceiling & Floor board
1	Ceiling board	Gypsum board / Aluminum board			500mm * 500mm
2	Floor board	Ceramic tile			500mm * 500mm
E,Window & Door
1	Window 1	Aluminum alloy sliding window			For Dimension and Quantity, please check the drawing
	Window 2	Aluminum alloy blind window (for Bathroom)			For Dimension and Quantity, please check the drawing
2	Door	Steel door / Wooden door			For Dimension and Quantity, please check the drawing
F ,Accessories
1	Accessories :	setscrew, pop rivet, self-tapping screw, screw,silicon sealant, canopy, etc.
2	Optional spare parts	exhaust fan, electricity system and water pipes, toilet, sink, shower, kitchen cabinet, etc.







Cut-open view:







 Main Steel Structure:





















Note:

The structure shouldn’t be adjusted and any accessories such as bolts and screws shouldn’t be disassembled after the completion of the house without negotiating with and getting approval from the manufacturer.





Fields of Application

1. Office

2. Canteen

3. Rest room

4. Restaurants

5. Conference room

6. Temporary shelter

7. Field work station

8. Residential housing

9. Temporary building on construction sites, etc.







Our factory:
