14 Seats Electric Mini School Bus ( KYGD14A )
Feature:
1.Manufacture direct supply, price, quality and delivery could be controlled.
2. Attractive appearance and friendly design, with steel chassis, independent suspension.
3. Could design and supply free logos, various color for option.
4. Not only supply the exist model, customized vehicles are accepted if can be manufactured.
| Key Components | |
| Power Source | Pure electric |
| Electric System | DC system |
| Battery | Lead-Acid Storage Battery |
| Motor | 5.5KW DC Motor |
| Controller | Curtis Controller |
| Charger | China origin, input 110V-240V~50Hz-60Hz, |
| Performance | |
| Passenger capacity | 2,4,6,8,11,14 |
| Max. Range (loaded) | 80-100km |
| Max. speed | Up to 40km/h |
| Minimum turning radius | 7m |
| Max. climbing ability (loaded) | Up to 30% |
| Max. movement after brake at speed of 20km/h | ≤4.5m |
| Max. loading weight | 1250kgs |
| Dimensions | |
| Overall dimensions | 4650X1460X1940mm |
| Min. ground clearance | 150mm |
| Wheelbase | 2660mm |
| Front wheel tread | 1200mm |
| Rear wheel tread | 1200mm |
| Body and Frame | |
| Frame | steel framework |
| Body | Fibreglass |
| Paint | the US Dupont paint |
| Wheel & Tyre | 155/80-R12(tubeless tyres) |
| Brake system | Front: Disk Brake, back: drum brake |
| Up to 7 kinds of standard color for option | |
Pictures show
Packaging Details:packed in steel crate
Delivery :15~20 days after confirm the contact, within 7 days if have in stock
Lead Time: 15~20 days after getting deposite, within 7 days if have in stock
Warranty: Warranty period 13 months, supply free spare parts during warranty period
After-sales: 1.Technology instruction when you have any problems.
2.The warranty is valid based on the broken that not made by human beings.
HENAN KINGWOO ELECTRIC VEHICLE MANUFACTURING CO., LTD. is a shareholding industrial enterprise which is made up of Jinlong holding group, Taiyougu investment group and voch group. The company covers an area of 710000 square meters, existing staff more than 500 people, and is one high-tech enterprise of electric vehicle research and development, production, and sales.
Henan Kingwoo electric vehicle manufacturing co., LTD. is the subsidiary company of Kingwoo technology specializes in the international market, directly responsible for the international market sales and service.
