Home > Products > Boom lift > 16 m Self-propelled Articulating Telescopic Pallet Lift Hydraulic Drive Boom Lift

16 m Self-propelled Articulating Telescopic Pallet Lift Hydraulic Drive Boom Lift

Name: 16 m Self-propelled Articulating Telescopic Pallet Lift Hydraulic Drive Boom Lift
Brand: Honty
Availability: InStock

FOB Price

US$ 45,000 - 95,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	Honty
Model Number	HTZZ-14	Lift Mechanism	Telescoping Lift
Lift Drive / Actuation	Electric Motor	Power	45KW/2200rpm
Rated Loading Capacity	230kg	Min. Lifting Height	2..38m
Max. Lifting Height	14.2m	Table Size	1.83*0.76m
Overall Dimensions	6.22.292.38m	Weight	7577kg
Certification	CE ISO	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

16m self-propelled articulating telescopic pallet lift hydraulic drive boom lift

What Is The Articulaing Boom Lift ?

---Where there is aerial work ,there is boom lift.

The HTZZ-14 4x4 offers one of the most impressive working envelopes in its class.

Its compact base allows it to maneuver easily in enclosed spaces and its extremely low overall weight helps to minimize transportation costs.

The HTZZ-14 4x4's 2.29 M wide ToughCage offers more space for materials and tools and a 150° jib-boom with 160° cage rotation increases accuracy when positioning the cage. The tough, impact-resistant composite base and larger cross-section steel rails of the Tough cage give strength and durability, while the multi-award winning provides additional operator protection.

The HTZZ-14 4x4 is available with two power options, Diesel-only or Hybrid power:

The Diesel-only option incorporates a versatile and efficient TIER IV compliant engine to deliver maximum traction and grade ability, making it ideal for rough or uneven ground.

The Hybrid option incorporates a smaller, power-optimized TIER IV compliant engine supported by the machine's battery pack for when extra power is needed. This maintains power and performance while reducing fuel consumption for maximum efficiency. The Innovative 'Diesel Re-Gen' feature also recharges the batteries without a mains power source, giving a 'fast-charge' whenever the machine is idle and the engine running. In addition, an electric-only mode allows zero-emission operation, making it ideal for indoor use, or for quiet, clean operation.

Both power options include Hontylift's advanced exhaust purification system, which greatly reduces Carbon Monoxide, Hydrocarbon and particulate emissions making either an environmentally conscious choice.

For more information regarding the HTZZ-14 4x4 or any other self propelled cherry picker, including the HTZZ-14 4x4 and SP50 4x4, please contact

* Not available on all models, check specification sheets for details of exact features.

Available Improved narrow aisle access

Bi-Energy Available

Optimizing Utilization

OVERALL WORKING RADIUS & HEIGHT

Product figure

Honty self propelled boom lifts have platform heights ranging from 10 m to over 18 m. All Honty self propelled boom lifts compact and maneuverable and can be driven from the platform in any boom position saving time and improving efficiency. With 'Narrow' and 4WD chassis options available* they are ideal for industrial or construction environments. Easy to use proportional controls make Honty self propelled boom lifts simple to operate and features such as telescopic booms, jib-booms and platform rotation maximize their effectiveness on any task.

Power options available on Honty self propelled boom lifts include battery, gas, diesel, Bi-Energy and now Hybrid (e.g. battery & diesel), combining the benefits of two power sources on the same machine.*

* Not available on all models, check specification sheets for details of exact features.

Optional type

Application

Frequently Asked Questions

1 Are you a factory or trading company?

--We are an integrated intustrial and trade company. So we have competitive price.

2 How about your service?

--Technical support on installation ,using and maintaince are available .so we have good servive..(video , online-service are available)

3 How does your factory do regarding quality control?

--Self-inspection department as well as third-party identification (CE. ISO9001),also accept you inspection. And welcome to visit our factory.

Packaging & Shipping

packaging: standard international packaging . The wooden case can be customized as the machine size. Water-proof.

shipping: The loading port is Qingdao,China. We will delivery your machine once your order done within 15 days.
