High Temperature Ovens Test Chamber
High Temperature Ovens Test Chamber
Main Technical Parameter
Model |
0-100 |
0-225 |
0-500 |
0-800 |
0-1000 |
|||||
Internal dimensions (mm) |
450*450*500 |
500*600*750 |
800*700*900 |
800*1000*1000 |
1000*1000*1000 |
|||||
Overall dimensions (mm) |
750*880*850 |
800*950*1000 |
1100*1100*1300 |
1100*1450*1400 |
1300*1400*1400 |
|||||
Technical structure | ||||||||||
Temperature range |
Ambient~+250 ℃ (Max to 400℃) |
|||||||||
Temperature fluctuations |
± 0.5 ℃ |
|||||||||
Temperature deviation |
± 2.0 ℃ |
|||||||||
Heating rate |
about 6 ℃ / min |
|||||||||
Control system | ||||||||||
Controller |
Digital PID Temperature Controller |
|||||||||
programmable color display touch screen, PC Link with software, R-232 interface (Optional) | ||||||||||
Temperature Sensor |
PT100 A-class |
|||||||||
Temperature Resolution |
± 0.1 ℃ |
|||||||||
Heating system |
Independent Nichrome electronic heating system |
|||||||||
Circulatory system |
Cold resistance and low noise centrifugal wind wheel |
|||||||||
Material | ||||||||||
Exterior material |
Steel Plate with Protective coating |
|||||||||
Interior material |
SUS304 stainlesssteel |
|||||||||
Insulation window |
Double thermo stability silicone rubber sealing |
|||||||||
Standardconfiguration |
2 sets of shelf , 1 copy of operating specification |
|||||||||
Timing Function |
0.1~999.9 (S,M,H) settable |
|||||||||
Environmental conditional |
5℃~+30 ℃ ≤85% RH |
|||||||||
Nominal power |
2500W |
3000W |
3500W |
4500W |
6500W |
|||||
Power Supply |
AC220V 50HZ |
AC220V 50HZ |
AC220V 50HZ |
AC220V 50HZ |
AC380V 50HZ |
|||||
Design and Construction
Test area
Test area is made of stainless-steel.
2 stainless steel shelves (adjustable)
LIB climatic test chamber have been certified by CE and RoHS compliance.
LIB team offer our services to all customers for all test chambers.
|
Pre-Sales Service * Inquiry and consulting support. * Offering quotation and specifications. * Provide test solutions. * Visiting our factory. |
|
After-Sales Service * 3 Years Warranty, Lifelong Follow-up Services. * Training how to install and operate the machine. * Training how to maintain the machine. * Response within 24 hours once got questions from customers. * Send spare parts within 2 days after got notice. * Engineers available to service machinery overseas to install and commissioning. |
Worldwide customers from America, Europe , Asian , Africa and Australia come our factory to
visit our plant, inspect of goods, training and study , have meeting for new more project.
Question: I need chambers very urgently, do you have stock ?
LIB: we have no stock, our standard delivery is 10 days , if you need in urgent , we can speed up the production ,will short to 7 days , customer should notice before order .
Question: How about your LIB payment terms?
LIB: Our payment is 50% with order, and 50% before delivery.
Question: Can LIB arrange delivery to our office (Lab)?
LIB: Yes, LIB can arrange shipping to your country and to your office ( Lab) by sea, by air, by train and by truck on conditions FOB, CFR, CIF, DDU and DDP for customers .
Question: Can we visit your plant before order?
LIB: We welcome and sincerely invite you or your team to visit our plant, we will help you to arrange hotel and pick you up from airport.
Question: Have you sold chambers to our country?
LIB: Now LIB climatic test chambers sold to more than 25 countries, like USA, Canada, Russia, UK, Italy, Germany, European Union, India, Pakistan, Philippines, Singapore, Vietnam, Thailand, Iran, Brazil ……and so on .
Question: Can you arrange installations and commissioning in our lab?
LIB: Firstly, for standard chamber we had 5 days commissioning before shipping , you just need link power in your lab, then can start to operate; Secondly; we had detailed operation manual with chamber , any problems you can find and solve in it; Thirdly, some of customized chambers we should to install and teach your team to operate .
Question: How about your warranty?
LIB: It is three years warranty for every LIB’s chamber, and lifetime service. Now LIB has 8 agents in the world, and in Europe (Italy) , America (USA) Middle East(Iran) had service office, we can in first time to solve your problems.
