2~8m working platform electrical steel/aluminum suspended platform ZLP 630 800 1000

1. Working platform, suspension mechanism

With hot galvanized steel,the suspension mechanism uses 80*80,70*70 square tube, thickness is 3.75mm, front and rear girder is 2.35mm thickness, middle girder is 2.48mm, thickness of working platform is 2.2mm.

2. Hoist

With famous brand of motor, large braking torque, unique anti-rope clamping device, when the rope is clamped,the alarming rings,the motor stops working, so that factor of safety is increased meantime, maintenance cost of hoist is reduced. Lubrication oil is 220# industry gear oil.

3. Safety lock

The lock cylinder uses special stainless steel, with strong impact resistance, higher toughness, wear resistant, long services life,safe and reliable.

4.  Control Panel / Control Box

 The electric components uses CHNT,SCHNEIDER brand, reliable quality,easy to maintain.

5. Counter weight

The shell of counter weight uses 1.5mm steel plate, the using life can be more than 5 years.

6. Wire rope

4*31sw high quality wire rope

Hoist and safety lock are packed in one plywood case, size 610*310*340mm;

Control box/ control panel is packed in a plywood case,size 570*440*270mm;

Other components are fastened by rope and then by pallet

20GP can load 8 sets with counter weight, 10~12 sets without counter weight

Langfang Xinghe Industry Co,Ltd, established in 1980 year, is professional in production,sales and rental of temporary suspended platform in China.

As a market leader and key player in suspended platform&cradle sector, since its establishment, we focus on facade solutions, high rise building cleaning&maintenance. Our team has long lasting experience and kowledge in design and production of suspended platform and related components. With technique creation, strict inspection,and perfect after-sales services, we are getting more and more domestic and overseas market share.

Our main products includes suspended platform/cradle ZLP630, ZLP800 with its components, hoist, safety lock, electric control box and other parts. All these components are made in our factory by our worker, it means stable and competitive quality, delivery and services.

 Advantage

1. The product of each order will be strictly tested one by one, the whole machinery will be test by over loading.

2. All of the components are produced by ourselves workers, the quality and the delivery time can be ensured.

3. As a factory, the cost of the goods can be controlled very well, you can get a more competitive price.

4. We can supply the on-line technical guidance, if your order quantity reaches our requirement, we can arrange our technical team to your country to setting equipment.

5. The important components of hoist , the warranty is 5~6 years, for example  gear.
