Special Low Maintenance Steel Suspended Wire Rope Platform / Electric Swing Stage Gondola / Suspended Cradle Scaffolding

FOB Price

US$ 1,700 - 2,250 / Set

1 Set(Min. Order)

Port Tianjin Port
Payment TermsT/T D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China		Brand Name	XINGHE
Model Number	zlp630

Product Description

Special low maintenance steel suspended wire rope platform / electric swing stage gondola / suspended cradle scaffolding

Introduction details :

1. Working platform, suspension mechanism

With hot galvanized steel,the suspension mechanism uses 80*80,70*70 square tube, thickness is 3.75mm, front and rear girder is 2.35mm thickness, middle girder is 2.48mm, thickness of working platform is 2.2mm.

2. Hoist

With famous brand of motor, large braking torque, unique anti-rope clamping device, when the rope is clamped,the alarming rings,the motor stops working, so that factor of safety is increased meantime, maintenance cost of hoist is reduced. Lubrication oil is 220# industry gear oil.

3. Safety lock

The lock cylinder uses special stainless steel, with strong impact resistance, higher toughness, wear resistant, long services life,safe and reliable.

4. Control panel / control box

The electric components uses CHNT,SCHNEIDER brand, reliable quality,easy to maintain.

5. Counter weight

The shell of counter weight uses 1.5mm steel plate, the using life can be more than 5 years.

6. Wire rope

4*31sw high quality wire rope

Item	zlp630 suspended platform	zlp800 suspended platform
Rated Loading	630kg	800kg
Lifting Speed	~9.5m/min	~8.5m/min
Platform size(LWH)	(32000mm)690mm*1180mm	(32500mm)690mm*1180mm
Suspension Mechanism	Rated exerted length of front beam	1.1m~1.5m
Suspension Mechanism	Terrain clearance of front beam	1.45m~1.75m

Type	LTD63	LTD80
Motor type	Customization	Customization
Power	2*1.5Kw	2*2.0Kw
Voltage	380v/415v/220v(50hz)	380v/415v/220v(60hz)
Speed	1400n/min	1400n/min
Braking torque	15N.M	15N.M

Safety Lock
type	LS30
	Angle of tilted locking rope	3°~8°
	Allowable impact force	30KN

Quality
Suspension platform	300kg	370kg
Hoist	52kg*2	56kg*2
Safety lock	5.5kg*2	5.5kg*2
Suspension mechanism	320kg(not including counter weight)	320kg(not including counter weight)
Electricity box	18kg	18kg
Complete machine	753kg	831kg
Counter weight	1000kg(25kg*40pcs)	1000kg(25kg*40pcs)

Loading quantity	20GP	12sets suspended platform
Loading quantity	40HQ	30sets suspended platform

Wire rope

Type

4*31SW+FC-φ8.3

Broken pulling force≥53500N

4*31SW+FC-φ8.6

Broken pulling force≥62500N

Cable line

Type

3*2.5+2*1.5YC-5(one picec)

Packaging & Shipping

Hoist and safety lock are packed in one plywood case, package size:610*310*340mm
Control panel is packed in a plywood case, package size:570*440*270mm
Other components are fastened by rope, than by pallet.
20GP will be loaded 8 set including counter weight, 10~12 sets without counter weight
