220V Single Phase 750watt,1000watt Digital AC Servo Driver With Position,speed,torque Control Mode
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
ADTECH
Model Number:
QS7AA030M
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3 Phase 400watt High Speed AC Servo Motor With 3000rpm,2500PPR Encoder FeedbackUS$ 1.00 - 1.00MOQ: 1 Set -
High-precision Stable Step Driver Q2BYG806MDNegotiableMOQ: 1 Set
-
High-precision Stable Step Driver Q2BYG404MANegotiableMOQ: 1 Set
-
2-phase Hybrid Step Motor With High-qualityNegotiableMOQ: 10 Sets
-
56 Series 2 Phase Hybrid Stepper Motor 56BYGNegotiableMOQ: 10 Sets
Place of Origin
China
Brand Name
ADTECH
Model Number
QS7AA030M
Motor Type
AC Motor
Feature Of Driver
- AC sine wave control, smooth torque, no impulse.
- 2500 line incremental photoelectric encoder, high positional accuracy, rotation positional accuracy can reach 1/10000R.
- Speed ration can be as large as 1:5000, has stable torque characteristics from low speed to high speed.
- Adopting high speed FPGA processing, motor fastest rotation speed can be 5000RPM.
- Rich and complete parameter setting can be configured with different ways of working and operating characteristics to adapt to different requirements.
- Possess position, speed and torque control mode, has applications in a wide range.
- Use intelligent Space Vector control (SVPWM), has much larger torque and much less noise than traditional SPWM.
- Up to three times overload design, stronger load ability.
- Perfect protection function: over current, overvoltage, over heat, encoder abnormal etc.
- Perfect condition monitoring function, such as positional deviation, rotate speed, feedback impulse, command impulse etc.
Paramenter Of Driver
| Input Voltage | AC220V -15%~+10% |
| Driver Current | 30A |
| Matching Motor | 750W~1500W |
| Using Temperatre | Working:45C Storage:-40C~55C |
| Relative Humidity | 40%~80% No Condensing |
| Atmosphere | 86~106kpa |
| Control Mode | 1.Position Control 2.Speed Control 3.Torque Control 5.Inside Pules Control 6.Electric Tool Carrier Control |
| Pulse Command | 1.Pulse+Direction 2.CW+CCW Pulse 3.Two-Phase AB Orthogonal Pulse |
| Control Precision | 0.01% |
| Response Frequency | <=200Hz |
| Pulse Frquency | <=500kHz |
| Speed Ratio | 1:5000 |
| Regenerative Brake | Internally Installed |
| Electronic Gear | 1/30000~30000/1 |
| Overload Capacity | <=300% |
| Feedback Pulse | 2500P/R |
| Protection Function | Over Current, Over Voltage, Overload, Over Heat, Lack Phase, Over Speed, Encoder Abnormal, Out Of Tolerance, Mode Abnormal Alarm |
section table
| Performance Paramenters | Servo motor NO. | ACH11120DC | ACH11150D | ACG11120BC | ACH11120BC/T | ACH13100C | ACH13150AC/T | ACH13150CC/T |
|
Matching Servo Driver NO. |
QS7AA030M | |||||||
| Flang Specification(mm) | 110 | 130 | ||||||
| Rate Power(kw) | 1.2 | 1.5 | 1.2 | 1.2 | 1.0 | 1.5 | 1.5 | |
| Rate Torque(Nm) | 4 | 5 | 6 | 6 | 4 | 10 | 6 | |
| Max.Torque(Nm) | 12 | 15 | 12 | 12 | 12 | 25 | 18 | |
| Rate Current(A) | 5.0 | 6.0 | 4.5 | 4.5 | 4 | 7.5 | 6 | |
| Rate Speed(rpm) | 3000 | 2000 | 2500 | 1500 | 250 | |||
| Rate Voltage(V) | 220 | |||||||
| Installation Size |
Rotor Inertia (kgm²/10^-4) |
5.4 | 6.3 | 7.6 | 7.6 | 8.5 | 19.4 | 12.6 |
| Shaft Diameter(mm) | 19 | 19 | 19 | 19 | 22 | 22 | 22 | |
| Body Length(mm) | 189 | 204 | 219 | 263 | 106 | 308 | 238 | |
| Weight(kg) | 5.5 | 6.1 | 6.7 | 9.7 | 7.7 | 12.3 | 9.3 | |
