hydraulic hose clip / high pressure solid hose clamp
Hydraulic hose clip widely applies in the vehicle, ship, construction, fire control, textile, the gasoline engine, the diesel engine, sprinkler irrigation machinery,mechanical equipment, the hose outlet gas and heating, is necessary for all kinds of hose interface tighten connecting fittings
1)Size: |
17-19&above |
||
2)Material: |
W1 |
All zinc-plated |
|
W2 |
Screw, axle and sleeve adopt galvanized iron,others adopt 200 series or 300 series stainless steel |
||
W4 |
Fully adopt 200 or 300 series stainless steel |
||
W5 |
All stainless steel 316 |
||
3)surface handle: |
Zinc-plated or stainless steel |
||
4)Band width: |
18mm/20mm/22mm/24mm/26mm |
||
5)Band thickness |
Galvanized iron |
Stainless steel |
|
0.6mm/0.8mm/1.2mm/1.5mm/1.7mm |
0.6mm/0.6mm/0.8mm/0.8mm/1.0mm |
||
6)Screw size: |
M5/M6/M8/M10 |
||
7)breaking torque |
5Nm/15Nm/25Nm/40Nm(min) |
||
7)Feature |
The blankholder of the band side is not easy to scratch the pipeline , protect the pipeline The pressure of the band is greater and play a role in protecting |
||
(1). 200 pcs/inner box, 10 inner boxes/ctn
(2). 100 pcs/inner box, 10 inner boxes/ctn
(3). 50 pcs/inner box, 10 inner boxes/ctn
(4). 25 pcs/inner box, 10 inner boxes/ctn
(1) More than 25 years experience
(2) Good quality and reasonable price
(3) Professional packing
(4) On time delivery
(5) 100% test before shipment
(6) Good After-service
