Auto Darkening Welding Mask With Solar Power

Auto Darkening Welding Mask With Solar Power thumbnail-1
Auto Darkening Welding Mask With Solar Power photo-1
US$ 15 - 25 MOQ: 200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hubei, China
Brand Name:
WELHEL
Model Number:
WH8000 series
Contact Supplier Request Quote Chat Now
Wuhan Welhel Photoelectric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Wuhan Ningbo Shanghai ect...
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hubei, China
Brand Name WELHEL
Model Number WH8000 series
Auto-Darkening Yes
Switch Time 0.15-0.80s
View Area 100*67mm
Solar Powered Yes
Sensitivity Stepless Adjustment
Power Supply Li-Mi & Solar Combination
Helmet Material ABS
Cartridge Size 110*90*8mm

Specifications

Replaceable Li-Mi & Solar Combination
Auto-darkening
Big viewing area at 100*67mm
UV & IR protection:shade15
ANSI/CE/ISO9001





Auto darkening welding mask with solar power



Mask: WH8000 series

Filter Optional: WH9**, WH7**, WH5**, WH4**, WH1**

Mask material: ABS



 Auto darkening welding mask with solar power





Auto Darkening Lens Specifications (technical parameters)



                     AUTO     DARKENING     LENS     SPECIFICATIONS
  Best Economic Solution
MODEL WH900 Series WH700 Series WH500 Series WH400 Series Single Shade Series
913 912 711 712 713 714 715 716 500 501 511 512 513 514 515 516 521 400 401 403 300 111 101 103
Cartridge Size (mm) 110* 90 110*90 110*90 110*90 110*90 108 x 50.8
Viewing Window Size (mm) 100*67 100*49 92*42 92 *42 100 *49 98 *35 98* 35 95*31
Lens Thickness (mm) 8 8 8 8 8 8 5
Weight (g) 108 105 103 100 90 45 36
Light State DIN4 DIN4 DIN4 DIN4 DIN3
Dark State DIN9-13 DIN9-13 DIN9-13 DIN5-9 / 9-13 DIN9-13 DIN11
Switching time (ms) 0.04 0.04 0.04 0.1 0.5
Delay time Adjustment Inside & Stepless (0.15~0.80s) √ √   √
Inside & Switch       (Fast/Slow 0.25s/0.70s)     √   √ √
Sensitivity Adjustment Inside & Stepless √ √   √
Inside & Switch       (Low/High)     √   √ √
Shade Adjustment Outside & Stepless √ √   √   √   √   √
Inside & Stepless   √   √   √   √
Grinding Outside √     √   √
Inside   √   √
Power Supply Solar power & Lithium Battery combination   √   √   √ √   √   √ √ √
Solar power & replaceable battery √   √   √   √   √
Solar power & rechargeable battery   √
Water & Dust proof   √
TIG enhanced √ √ √   √
Warranty (years) 2 2 2 2 2 1
Certification CE EN379 1/1/1/2 1/1/1/2 1/1/1/2 1/2/1/1 1/1/1/2 1/1/1/2   1/1/1/2 1/2/1/2
ANSI Z87.1   √ √



Functions of custom welding helmet:



Grinding

TIG enhanced

Water & Dust proof

Warranty (years): at least 1 year





Certificate for custom welding helmet



CE



EN379



ANSI Z87.1



ISO9001:2008



Auto darkening welding mask with solar power Auto darkening welding mask with solar power Auto darkening welding mask with solar power
