ADT-HC4500 Plasma Cutting Controller 1

ADT-HC4500 Plasma Cutting Controller 1 thumbnail-1
ADT-HC4500 Plasma Cutting Controller 1 thumbnail-2
ADT-HC4500 Plasma Cutting Controller 1 thumbnail-3
ADT-HC4500 Plasma Cutting Controller 1 thumbnail-4
ADT-HC4500 Plasma Cutting Controller 1 photo-1
ADT-HC4500 Plasma Cutting Controller 1 photo-2
ADT-HC4500 Plasma Cutting Controller 1 photo-3
ADT-HC4500 Plasma Cutting Controller 1 photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ADTECH
Model Number:
HC4500
Contact Supplier Request Quote Chat Now
ADTECH (Shenzhen) Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ADTECH
Model Number HC4500

Specifications

1.new style cnc plasma cutting controller based on HC4300.
2.It adopt ARM9 processor, super large customized type

  • ARM9 high-speed Microprocessor and super large programmable FPGA
  • Real time multitask control technology and hardware interpolation technology
  • 7 Inch real color display screen, Friendly and easily operation interface,
  • Supporting multi language display;
  • All Photovoltaic isolation control, super large anti-interface ability;
  • Large storage space process file: 256M, demand complicated/large program running and processing
  • Plasma /flame controller can control 3 step/servo motor at the same time, which adopt doubt axis at one time or develop 3 axis according customer requests;
  • Graphic library: 63 graphs, which can cutting hole or slice as choose;
  • Graphic Dealing function, which are supporting edit Radom rotation, correction and mirror image function etc;
  • Delay, preheating, perforating, changing nozzle, moving parts, moving parts etc process control;
  • Break point recovery function
  • USB, RS232 serial communication control, directly read file buy U disk
  • Customized software: strong>it can apply for Plasma, Punch and engraving function within one machine, simple laser cutting etc.



Power Request

DC 24V 50/60Hz

Power Dissipation

<10W

Work Temperature

0°C-60°C

Storage Temperature

-20°C-80°C

Work Humidity

20%-95%

Storage Humidity

0%-95%
Digital Input:
  • Channel: 32, All Photovoltaic isolation
  • Input Voltage: 12-24V DC
  • High Level >4.5V
  • Low Level <1.0V
  • Isolation Voltage: 2500V DC
  • Counting Input:
  • Channel: Spindle ABZphase coding input, All Photovoltaic isolation
  • Maximum counting frequency: 2MHz
  • Input Voltage: 5-24V DC
  • High Level>4.5V
  • Low Level<1.0V
  • Isolation voltage: 2500V DC
Pulse output:
  • Channel: 3 Axis Pulse, 3 axis direction, All photovoltaicisolation
  • Maximum pulse frequency: 2MHz
  • Output type: 5Vdifferential output
  • Output mode: Pulse +direction or pulse + pulse
Digital Output:
  • Output Channel: 16, All photovoltaic isolation
  • Output type: NPN open-collectorout put 12-24V DC, Max current 100mA.
  • RS-232 Baud rate(bps):
  • 1200,2400,4800,9600,19200,38400,57600,115200
