2 Axis Brush Filling Machine

2 Axis Brush Filling Machine thumbnail-1
2 Axis Brush Filling Machine photo-1
US$ 1 - 1 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Adtech
Model Number:
BM-CNC2Z23P
Contact Supplier Request Quote Chat Now
ADTECH (Shenzhen) Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Adtech
Model Number BM-CNC2Z23P

Specifications

1)Brush filling machine can make cleaning brushes with flat surface.
2) 2 axis movement cleaning brush filling machine



2 Axis Brush filling Machine

  BM-CNC2Z23P 2 Axes Flat Brush Tufting Machine
Item Model BM-CNC2Z23P
1 NO. of axis 2-axis
2 The stroke of X axis  200mm,provide flexible customize for customer.
The stroke of Y axis  150mm,provide flexible customize for customer.
3 Setting of Worktable high-precision straight-line rail and ball screw,steady and durable.
4 Material of Brush Handle Polyethylene, polystyrene, return materials, wood
5 Material of Filaments PP,PET,PVC,STEEL WIRE
6 Application To tuft varieties of flat  brushes
7 Diameter of Filaments  0.08mm-1.2mm
8 The length of filament(outside the hole) 15mm-50mm
9 Diameter of hole  2mm-4mm
10 Colors of Brush Filaments single color or double colors
11 Maximum Tufting Speed 4~6 holes/second
12 AC motor Italian Brake Motor
13 Type&Brand of Driver/Motor stepper motor&driver , can adopt some brand motor&driver requested by users.
14 Adjust Speed Frequency-conversion stepless-adjustable speed
15 Replaceable Fixture FMS type. It can be easily changed to make other kinds of brushes.
16 Head mode Staple
17 Programme Storage Store 2000 programmes,each can imput 100 thousand processing data.
18 Program System CNC system,high precision,stability and efficiency
19 Dimension(L*W*H)  1250×1150×1600mm
20 Gross weight  350KG
21 Power 3-phase 380v, 50Hz
22 Total power About 600w
23 Compressed Air Pressure  0.6-0.8Mpa

Feature
1 With 5.7 LCD screen,Chinese and English interface.
2 Supports data switching.The controller can be used as a U-Disk,and it also can be connected with  U-Disk.
3 Convenient to adjust the hole position with the handwheel.
4 Long life , nice feel,and reliable keypad.
5 Safe to operate.With alarming fuction ,the system will give an alam and stop to run  when the machine fails.
6 Full Featured, Editing functions of processing data, such as ADD, ALT,INSERT,DELETE, makes it convenient to solve these problems: the deviation of hole position, hole-repeating and hole-missing.
7  Easy to operate and program.
8 Large capacity,it can store 2000 programmes and each programme can imput 100,000 processing data.
9  Convenient to find the specific program  by choosing the program number.
10 Standard designed circuit reduces the line interference and makes sure send the correct singal.
11 You can confirm whether the hole postion is right by step test after the program is saved.
12 Reasonable designed mechanical part position makes the machine good features.
13 Standard spare parts offered.
14 Spare parts are all made by our factory.It is very easy to replaceable.
