BV-DS0132 standard wafer EPDM liner butterfly valve
Description of EPDM liner butterfly valve :
This EPDM liner butterfly valve is developed based on the wafer butterfly valve and advanced technology introduced from foreign country.In addition to the feature of the wafer butterfly valve.It has strong corrosion resistance and no-pin.This product is stable for throtting-off and adjusting flow,and can be installed in pipelines in the industries of petroleum processing,chemicals,food me-decline,textile,paper making,hydroelectricity engineering,ship bulldozing,water supply and sewage,metallurgy,energy engineering as well as light industry,etc.
Material of EPDM liner butterfly valve 's main parts:
No. |
Part Name |
Material |
1 |
Body |
Ductile Iron/ optional |
2 |
Disc |
CF8M/CF8 |
3 |
Seat |
EPDM/NBR |
4 |
Stem |
Stainless Steel314/Stainless Steel316 |
5 |
Bushing |
PTFE/Lubricating |
6 |
O ring |
PTFE |
Features of EPDM liner butterfly valve :
1.wide selection of materials, applicable for various medium.
2.Bubbles-tight sealing with no leakage under the pressure test.
3.Long service life.standing the test of thousands opening,closing operations.
4.Flow curve tending to straight line. Excellent regulation performance.
5.Simple and compact construction,quick 90° on-off operation.
Our service tips :
1. Customer always firs,customer satisfaction is our goal.
2. 18 months of quality assurance, let customers buy at ease.
3. We are the real factory sales, we will provide you the best quality products with reasonable price .
If you have any inquiry or any problems about the products, please feel free to contact me, and I am pleased to supply service for you.
.
.
.
