5.0 mp CMOS Sensor HD 1080P IP CCTV Camera Module,Client Software,Support NVR Storage Mobile Phone View,Support ONVIF(SIP-1080P)

5.0 mp CMOS Sensor HD 1080P IP CCTV Camera Module,Client Software,Support NVR Storage Mobile Phone View,Support ONVIF(SIP-1080P) thumbnail-1
5.0 mp CMOS Sensor HD 1080P IP CCTV Camera Module,Client Software,Support NVR Storage Mobile Phone View,Support ONVIF(SIP-1080P) thumbnail-2
5.0 mp CMOS Sensor HD 1080P IP CCTV Camera Module,Client Software,Support NVR Storage Mobile Phone View,Support ONVIF(SIP-1080P) thumbnail-3
5.0 mp CMOS Sensor HD 1080P IP CCTV Camera Module,Client Software,Support NVR Storage Mobile Phone View,Support ONVIF(SIP-1080P) photo-1
5.0 mp CMOS Sensor HD 1080P IP CCTV Camera Module,Client Software,Support NVR Storage Mobile Phone View,Support ONVIF(SIP-1080P) photo-2
5.0 mp CMOS Sensor HD 1080P IP CCTV Camera Module,Client Software,Support NVR Storage Mobile Phone View,Support ONVIF(SIP-1080P) photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SMTSEC
Model Number:
SIP-1080P
Contact Supplier Request Quote Chat Now
Shenzhen Smart Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SMTSEC
Model Number SIP-1080P
Type Digital Camera
Sensor CMOS
Technology Infrared



Product Description

Client software,Support NVR Storage Mobile phone view,Support ONVIF 5.0 mp CMOS sensor HD 1080P IP CCTV Camera Module(SIP-1080P)



> HD 1080p IP Camera
> 5.0 mp CMOS sensor
> H.264 Dual-stream
> AVI video format
> 1080P 25fps,1920P 10fps
> Mobile phone view,Support ONVIF
> Client software,Support NVR Storage


Model

SIP-1080P

SIP-1080PA

Camera Type

HD 1080P IP Camera Module

Camera



Image Sensor

1/2.5 inch 5.0 Megapixel progressive CMOS sensor

DSP

TI Davinci DM368 DSP 32 dual-core , pure hardware compression

Day/Night

Auto

IR-Cut

Support

Min.Illumination

Color 0.6Lux/F1.2,B/W 0.08 Lux/F1.2

Electronic Shutter

1/50(1/60)s-1/100,000s

Lens Mount

CS Mount (support Auto-Iris Lens)

Digital Zoom

Support

Video/Audio



Compression Standard

H.264

Compression Technology

Dual-stream compression technology

System Structure

Pure hardware compression, watchdog,32M FLASH,128M DDR2;

Video Frames

Real-time PAL 25fps,NTSC 30fps   1-30fps Adjustable

Bitrate

500~8000Kbps Adjustable

Bitrate Control

CBR/VBR/CVBR

Audio Coding Standard

N/A

AAC / G 7.11

Audio Volume

N/A

0-100 Adjustable




Resolution

Main Stream: 2592X1920 10fps,2048X1536 17fps,1920X1080 25fps

Sub Stream:D1,VGA,640X360,480X270,CIF,QCIF

Parameter Settings

Brightness, contrast, chroma saturation,Backlight Control,Mirror

Privacy Mask

Support  4 area can be set

Image Capture

Image quality , capture speed

Time and Title

Transparency, Time position, Time Format, Title Content

Network



Protocol

RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP/SMTP

Onvif

Support Onvif 2.0

User Permission

Multi-user Classification Management

Phone monitoring

Support iPhone and android  Mobile phone view

SDK

 Provide open SDK

Alarm

Support Motion Detection, Linkage Alarm, Linkage recording, Video Loss Alarm

Interface



Audio Input

N/A

1CH input

Audio output

N/A

1CH output

USB Interface

1 USB interface ( Max: 64G) , front storage supported

Video Output

1CH Video output, Support CVBS standard, PAL/NTSC Optional

Network Interface

1 RJ45 Ethernet interface, 10/100M adaptation

WIFI#

 WIFI 802.11bgn

3G#

WCDMA 3G wireless networks

RS485 Interface

N/A

RS485 interface

Alarm Interface

N/A

1CH input/1CH output

Other



Work Environment

-10°C- +60°C;≤95%

Power Supply

DC 12V

Product Size

38X38X38mm

Package Size

50X50X50mm

Net Weight

0.2kg

#The regular camera doesn't have WIFI,3G functions. If you need WIFI,3G functions, please consult with us.








Packaging & Shipping



China Post (10-30 days)
EMS (5-15 working days)
DHL (3-5 working days)
UPS (3-5 working days)



•The most reliable, affordable way of shipping method deponds on your address.
•Online tracking number will be emailed to buyer through email.
•We dont take any responsibility for any custom delay.





Our Services





•All products have been checked and packaged in good condition before dispatch.

•All products have 1 year warranty.
