Diesel Welding Generator

Name: Diesel Welding Generator
Brand: WANTONG
SKU: 107769849
Availability: InStock

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

WANTONG

Model Number:

WTD120

Fuan Wangwantong Electric Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou or other Chinese port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name WANTONG

Model Number WTD120

Specifications

WANTONG Diesel Welding Generator with dual function, elegant apperance, good quality alternator and engine.

One Unit, Dual Function

WANTONG Welder & Generators are advanced products with dual functions-welding & generating,

which brings more economical products for the consumer.

Simultaneous Use

Generating and welding can be operated simultaneously, while welding operation won't impact on the waveform

and voltage of the generating operation.

Perfect Welding

The unit can achieve perfect waveform of the welding voltage.

Excellent Electricity

New Automatic Voltage Regulator (AVR) and damper winding further enhance the electricity performance

with extremely low voltage regulation and minimum waveform distortion.

Easy Maneuver Ability

Light weight and compact design improves on-site maneuverability and save a lot of storage space.

And its two or four durable castors are helpful to its easy transportation.

Wide Application

The welding arc is super smooth to get the perfect welding quality in all kinds of the applications.

Furthermore, its welding current regulation is wide enough to suit most of welding rods.

Parameter

Model	WTD120
Rated Current (A)	100
Rated Voltage (V)	21-25
Welding Current Range (A)	40-120
Applicable Electrode (φ)	1.2-2.5
Duty cycle	120A/20%, 100A/60%
Generator voltage waveform distortion rate	5%
Phase	Single Phase
Frequency (Hz)	50/60
Rated Output (kw)	1.5/1.7
Rated Voltage (V)	110,120,220,230,240
Power Factor	1.0
Model	WTD178F
Max. Output(HP)	6.0
Displacement(cc)	306
Type	Single-cylinder, 4-stroke, air-cooled, vertical
Compression ratio	20:01
Starting System	Recoil
Lubrication System	Forced lubrication
Cooling System	Air cooled
Fuel Tank (L)	3.5L diese
Oil Capacity (L)	1.1
Noise Level(at 7m)	76
Dimension(LXWXH)mm	735x460x530
G.W (kg)	75
