12v Motorcycle Handlebar Smartphone USB Charger Power Adapter

US$ 1 - 6.99 MOQ: 3000 Sets

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Model Number:

MPS

Shenzhen Yutiantang Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name YT

Model Number MPS

Usage Mobile Phone

Output Type DC

Connection Plug In

Specifications

motorcycle handlebar charger
1.I/p:DC6-24v
2.Max current:500-1000mA
3.USB:5v 2000mA
4.CE certificate,1 year warranty

12v Motorcycle Handlebar Smartphone USB Charger Power Adapter

Input voltage	DC 6-24V
Output voltage	DC 5V
Maximum charging current (USB port)	2000mA
Protection	Reverse voltage protection Short-circuit protection Overload protection Waterproof protection
Certificate	CE
Warranty	12 months

3A blade fuse
Waterproof gland for USB cable
Cable ties
USB power connector
Water Resistant
Weather cap
On/Off Switch Box	593924mm
Battery terminals to Switch box	80cm
Switch box to USB connection	1m

Built-in 3A fuse and a waterproof voltage regulator.
About on/off switch is a control current output, can be charging to any mobile phones.
Total length is 1780mm, with cable ties can make you one place tie on motorcycle what you can easily charger.
Easy and convenient operation, easy to store on a motocycle.
We accepted OEM and ODM order.
Approval CE certificate.
One year warranty with satisfying after-sales service.

Remove battery terminals; connect red lead to positive and black lead to negative terminal.
Run the cable along frame tube, keeping away from any hot areas, ensure easy access to the on/off switch on black control box, secure any loose wires with the cable ties provided, secure black control box to the motorcycle using cable ties in an area away from direct heat. (If mounting the switch on handlebars, ensure bars move unobstructed after securing all cables.)
Slide the yellow gland around your phone's data/charging connection cable.
Remove waterproof cover from the charger; plug in usb charger lead with the yellow gland to from a waterproof seal.
Switch on the charger with black domed switch.
Whilst leaving the motorcycle for long period, switch off to avoid draining car battery.
