Brass Ball Valve With Level Handle

Brass Ball Valve With Level Handle photo-1
US$ 0.8 - 2.5 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Ball
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Standard or Nonstandard Standard
Structure Ball
Pressure Medium Pressure
Power Hydraulic
Material Brass
Temperature of Media Normal Temperature
Media Water
Port Size DN25
Place of Origin Zhejiang, China
Model Number 2021
Brand Name SY

Specifications

1) NSF,FM,UL Approved Brass Ball Valve Sweat
2) Size Range : 1/4" - 4"
3) Full port, blowout-proof stem
4)Lead free option

Specifications

Fegular checking on line from production in each workshop,one special inspector inspect the goods in random during the periond o


No. Component material
1 body brass
2 bonnet brass
3 ball brass
4 seat ring teflon
5 stem brass
6 packing ring teflon
7 washer brass
8 handle aluminium
9 nut iron



W-1010:brass ball valve with aluminium lever handle F×F

1,Techinical Standard Nominal Pressure:(Brass Body)2.0MPa
2,Suitable Medium:Water,Non-Causticity Liquid&Saturated Steam
3,Working Temperature:-20<t<180
4,Parallel Thread Conform To ISO-228-1:2000
5,Anti-Oxygen Glue Applied To Join Body&Bonnet
6,Nickle Plated
7,Brass body & Brass Ball
  Brass Body & Iron Ball
  Zinc Body & Iron Ball

8,Size:1/2",3/4",1",11/4" 11/2",2",21/2" ,3",4"

Quality and Inspection:
Fegular checking on line from production in each workshop,one special inspector inspect the goods in random during the periond of the production
