Product Features:
1) completely controlled by CPU increased the high stability of the inverter.;
2) With humanized design, when the AC cut off, the unit will start to supply power automactically , when the AC comes back, it will take powers from AC and turn to recharge the batteries automatically.
3) With all sides protections, protections against output short-circuit, overload protection (when it overload, it will close the unit automatically, when you reduce the load, then it will return to work automatically), low-voltage input protection, over-voltage input protection.
4) With charger built-in.
5) output waveform is pure sine wave: 220V/230/240VAC+/-3%, 50HZ+/-2%.(Can be 120VAC, 60HZ, optional).
6) it can drive inductive loads, such as tube-lights, TV sets, air-conditioner, fans, refrigerators, computers,motors, wind generator, solar system ,gasline generator and so on.
7) with high transfer efficiency, we can make our inverter transfer efficiency up to 85%---90%.
8) with communication port: RS232, SNMP card for option.
9) With LCD display or LED display for option.
Technical Parameters:
Model DY-**** |
I 300 |
I 400 |
I 500 |
I600 |
I 750 |
I 1000 |
|
Rated capacity (W ) |
300W |
400W |
500W |
600W |
750W |
1000W |
|
Battery DC voltage |
12VDC |
12V/24VDC |
24VDC |
||||
input |
Public power range( VAC) |
100V/110V/120V/127V/220V/230V ( +25%, -35% ) |
|||||
Frequency(HZ) |
50HZ/60HZ +/- 10% |
||||||
|
output |
waveform |
Pure sine wave |
|||||
Frequency(HZ) |
Commercial power supply : shared frequency with the public power inversion state 50/60hz+/-0.5 |
||||||
Voltage range(VAC) |
100VAC/110VAC/120VAC/127VAC/220VAC/230VAC +/-10% ( Auto-sensing) |
||||||
Transfer time |
Less than 4ms ( including detecdtion time) |
||||||
protections |
overload |
UPS automatically shut-down if overload exceeds 120% of normal value for 10 seconds, and 150% for 1 seconds. |
|||||
Short-circuit |
UPS output is cut off immediately or input circuit breaker protection |
||||||
|
Battery |
Type |
Sealed lead acid maintenance free battery |
|||||
Recharge current |
Maximum 15Amps |
||||||
Battery protection |
Automatic self-test, discharge protection, over-charging protection, smart management system. |
||||||
Display |
LED/LCD |
For option |
|||||
Unit size (mm) |
320 * 130 *190 |
||||||
Shiping size (mm) |
2pcs packed in one carton, 480 *430 *315 |
||||||
Net weight ( KG ) |
5.0 |
6.0 |
7.0 |
8.0 |
10.0 |
11.0 |
|
Gross weight ( KG ) |
14.0 |
16.0 |
18.0 |
20.0 |
24.0 |
26.0 |
|
Model DY-**** |
I 1200 |
I 1500 |
I 1800 |
I 2000 |
I 2500 |
I 3000 |
|
Rated capacity (W ) |
1200W |
1500W |
1800W |
2000W |
2500W |
3000W |
|
Battery DC voltage |
24VDC |
24VDC/48VDC |
|||||
input |
Public power range( VAC) |
100V/110V/120V/127V/220V/230V ( +25%, -35% ) |
|||||
Frequency(HZ) |
50HZ/60HZ +/- 10% |
||||||
|
output |
waveform |
Pure sine wave |
|||||
Frequency(HZ) |
Commercial power supply : shared frequency with the public power inversion state 50/60hz+/-0.5 |
||||||
Voltage range(VAC) |
100VAC/110VAC/120VAC/127VAC/220VAC/230VAC +/-10% ( Auto-sensing) |
||||||
Transfer time |
Less than 4ms ( including detecdtion time) |
||||||
protections |
overload |
UPS automatically shut-down if overload exceeds 120% of normal value for 10 seconds, and 150% for 1 seconds. |
|||||
Short-circuit |
UPS output is cut off immediately or input circuit breaker protection |
||||||
|
Battery |
Type |
Sealed lead acid maintenance free battery |
|||||
Recharge current |
Maximum 15Amps |
||||||
Battery protection |
Automatic self-test, discharge protection, over-charging protection, smart management system. |
||||||
Display |
LED/LCD |
For option |
|||||
Unit size (mm) |
460*220*385 |
||||||
Shiping size (mm) |
520*285*480 ( separate package ) |
||||||
Net weight ( KG ) |
19 |
22 |
25 |
27 |
29 |
31 |
|
Gross weight ( KG ) |
21 |
24 |
27 |
29 |
31 |
33 |
|
