Long Hole Drill Machine, Dth Long Hole Drill Button Bit, T38 Button Bit

Long Hole Drill Machine, Dth Long Hole Drill Button Bit, T38 Button Bit thumbnail-1
Long Hole Drill Machine, Dth Long Hole Drill Button Bit, T38 Button Bit photo-1
US$ 25 - 100 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
New Diamond
Model Number:
Button Bit
Contact Supplier Request Quote Chat Now
Hunan New Diamond Construction Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
changsha
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hunan, China
Brand Name New Diamond
Model Number Button Bit
Type Drill Bit
Machine Type Drilling Tool
Certification Other, CCIS
Material Carbide
Processing Type Forging
Use Ore Mining

Specifications

1. 15 years manufactuerer
2. Certificate: ISO9001:2008
3. Material:Carbide steel

long hole drill machine, dth long hole drill button bit, T38 button bit



(special good for mining, offer other spec. & OEM) :





Name of Product

Diameter

Tip Size(mm)

No. of Flushing Holes

Weight

(kg)

Part-No.

mm

Gauge

Front

Side

Front

Normal Thread T38

57

5*11

3*10

1

1

1.6

N57F5-T38

64

5*12

3*11

1

1

1.6

N64F5-T38

76

5*14

3*12

1

2

2.4

N76F5-T38


Normal Thread T38

64

8*9

4*9

2

2

1.8

N64F8-T38

76

8*11

4*10

2

2

2.6

N76F8-T38

89

8*12

6*11

2

2

3.3

N89F8-T38

102

8*13

6*12

2

2

4.7

N102F8-T38


Normal Thread T38

64

6*10

4*9

0

3

1.7

N64D6-T38

70

6*11

4*10

0

3

2.2

N70D6-T38

89

6*14

4*12

0

3

4.3

N89D6-T38


Normal Thread T38

64

8*9

5*8

0

4

1.7

N64D8-T38

70

8*10

5*9

0

4

2.2

N70D8-T38

76

8*11

5*10

0

4

2.7

N76D8-T38

89

8*12

6*11

0

4

3.3

N89D8-T38

102

8*13

6*12

0

4

4.7

N102D8-T38
 Retract Thread T38

60

8*9

3*9

2

2

1.7

R60F8-T38

64

8*9

4*9

2

2

2.0

R64F8-T38

70

8*10

4*10

2

2

2.4

R70F8-T38

76

8*11

4*10

2

2

3.2

R76F8-T38

89

8*12

5*12

2

2

5.8

R89F8-T38
  Retract Thread T38

64

8*9

5*9

0

4

1.9

R64D8-T38

70

8*10

5*10

0

4

2.4

R70D8-T38

76

8*11

5*10

0

4

3.3

R76D8-T38

89

8*12

6*11

0

4

5.3

R89D8-T38



Bit face shape selection:

1. Drop Center Bit

For high penetration rates in soft to medium hard and fissured rock formations. Low to medium air pressures. Maximum hole deviation control.

2. Concave Face

The all-round application bit face specifically for medium hard and homogenerous rock formations. Good hole deviation control and good flushing capacity.

3. Convex Face

For high penetration rates in soft to medium-hard with low to medium air pressures. It is the most resistance to steel wash, and may reduce the load and wear on the gauge buttons, but poor hole deviation control.

4. Double Gauge Face

This kind of face shape is suitable for fast penetration rates in medium to hard rock formations. Designed for high air pressures and good resistance to steel wash step gauge bit.

5. Flat Face Bit

This kind of face shape is suitable for hard to very hard and abrasive rock formations in applications with high air pressures. Good penetration rates an resistance to steel wash.

long hole drill machine, dth long hole drill button bit, T38 button bit



Carbide button shape selection:

1. Domed/Round Button

2. Parabolic/Semi-Ballistic Buttons

3. Ballistic Button

4. Sharp Button

5. Flat Button

long hole drill machine, dth long hole drill button bit, T38 button bit
