HGJ Air Flow Pipe Dryer for /sawdust

Name: HGJ Air Flow Pipe Dryer for /sawdust
Brand: hyph
SKU: 107595407
Availability: InStock

US$ 1,000 - 6,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Henan, China

Brand Name:

hyph

Model Number:

HGJ-III

Henan Double Elephants Machinery I/E Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name hyph

Model Number HGJ-III

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Sawdust pipe dryer
1.perfect technical design with less labor
2.high efficiency and low energ
3.environment-friendly

Working principle

In the dryer, high speed hot air stream sustain raw material in the suspending state, then the material is dried. Since air

stream speed is very high,and mateirls suspending in air stream, the heat transfter surface between air and raw mateiral is

large,so the heat transfer rate is high.

Dryed material

It is special suitable for drying heat sensitive material like sawdust, rice hull, milled wheat straw, milled cotton/ corn stalks and so on. It

also can be used for drying the grain better.

Feature

The HGJ SERIES dryer has the feature of low cost and high efficient. It can reduce moisture from 40-45% to 8-12%.

Fuel

Fuel for the furnace: wood waste, coal. Waste oil and so on.

Model and main data

Model	HGJ-I	HGJ-II	HGJ-III
Capacity-kg/h	300-400	400-500	800-1000
Diameter of raw-mm	< 3mm & < 5mm	< 3mm & < 5mm	< 3mm & < 5mm
Air temperature-°C	180°C~250°C	180°C~250°C	180°C~250°C
Centrifugal power-Airlock power kw	4	5.5	7.5
Material in feed	20mm	20mm	20mm
Consumption-kg/h	10kg/h	20kg/h	25-30kg/h
Weight/kg	2000	3000	4500
Dimension-meter	200.852.2m	300.852.5	500.952.7
Moisture-max-°C	35-45	35-45	35-45
Dried-max-°C	8-12	8-12	3-10
