IP65 China factory good quality aluminum alloy energy-saving 50w Led power explosion proof luminaire RFBL157
power explosion proof luminaire Application:
Hazardous zones: 1, 2, 20, 21, 22
Gas : IIA IIB IIC
Dust: Zone 21 (Group E Only). Zone 22
Temperature :T1~T6
Led explosion-proof platform light meets high requirements and damp environments.
Ideal for use in oil fields, chemical plants, power plants, petroleum, painting areas & and areas with dust.
power explosion proof luminaire Features and benefits
1. safe and reliable . Led explosion-proof platform light are all with CE/CCC/ MA/IOS 9001 approved!
2. the 4th generation green protection environments ,high efficiency of light ,almost maintenance-free operation due to long service life of the LED
3. reasonable struction . light source cavity independent, excellent thermal conductivity.
4. Optical science. Special design, high efficient, full range of lighting; downy and anti-dazzle.
5. Modular design. Standard modular design convenient for change and reduce cost
6.Durable . The aluminum body is powder coated for anti corrosion, which is dust and water proof.
Specification of power explosion proof luminaire
| Technical parameters of power explosion proof luminaire | |||||
| No | Specification | unit | Reference values | ||
| 1 | Rated Voltage | V | AC220 | ||
| 2 | Frequency | Hz | 50/60 | ||
| 3 | Light source(LED) | Power | w | 50 | |
| Luminous flux | 50 | lm | 4000 | ||
| service life of light source | h | 50000 | |||
| 4 | The introduction of cable(diameter) | mm | 8~12 | ||
| 5 | Dimensions | out diameter | mm | 200 | |
| Length | 350 | ||||
| 6 | weight | kg | 5.5 | ||
| 7 | Screw thread of inlet | G3/4'' | |||
| 8 | Protection grade | IP67 | |||
| 9 | Anti Corrosion | WF2 | |||
| 10 | Insulation Grade: | I | |||
| 11 | Ex code: | Exde II C T6 | |||
installation drawing of power explosion proof luminaire
light distribution curve of power explosion proof luminaire
1
Related power explosion proof luminaire Some of model light have three rated power for your select , satified to your different demands.
| RFLB103 | RFLB153 | RFLB156 | RFBL164 | RFLB165 |
| RFLB104 | RFLB154 | RFBL160 | RFLB162 | |
| RFLB105 | RFLB155 | RFLB158 | RFLB161 | |
Packaging Details: regular packing or customized for power explosion proof luminaire
Delivery Detail: 10-20days after receiving the 30%deposit for power explosion proof luminaire
Quality Guarantee
Thank you for purchasing power explosion proof luminaire of Wenzhou Recen Lighting Electrical Co., Ltd.. Our products are in strict accordance with the ISO9001 quality control standards. power explosion proof luminaire warranty is for 3 years (Light bulb for 1 year). In three years, any failure under normal use is repaired by our company for free (Free materials and repairs). contact our company's marketing service department, and we will provide you with high quality and efficient services.
Why us
Because we believe in providing quality not just the first time, but every time:
High Customer satisfaction
Various of products
Competitive price
OEM/ODM are welcomed
Q: Which areas need to use explosion proof light?
A: It meets the standards and requirements for hazardous environments. Ideal for use in oil fields, chemical plants, power plants, petroleum, painting areas and areas with dust.
Q: What is the advantage of explosion proof light?
A: It make the worker more safe, because the lamp having function with explosion-proof, dust proof and water proof. In flammable and explosive area to safe work.
Q: Do Led have a longer life than incandescent bulbs?
A: Yes. Incandescent bulb generally last 500-2000 hours, whereas Led may last for 20000-50000 hours or around 20-40 years. this means Led may last 25 times longer than incandescent.
Q: Do the surface of explosion proof light will rust?
A:No, we choose the advantage spay printing of surface, no rust, do not change color, anti rain, could be use outfield for a long terms
Q: How does your factory do regarding quality control?
A: Quality first. We always attach great important to quality control form begin to end. Our factory has gained CCC,CQC authentication.
