HC-2085 Mobile Waste Oil Suction

Name: HC-2085 Mobile Waste Oil Suction
Brand: HPMM
SKU: 107567753

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

HPMM

Model Number:

HC-2085

Hui Peak Machinery Manufacture Co., Ltd. (HPMM)

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name HPMM

Model Number HC-2085

Features

.Strong vacuum extraction system, fast, safe and easy extract used oil and other fluids out from vehicles.

Suitable for cars, boats, motorcycles and small engines.

Equipped with steel probe holder which is never broken and provide safe protection for sunction probes.

.Many diameter of probes(included 5mm, 6mm, 7mm, 8mm) made by copper and flexible PVC.

. Dia.5mm probe and different color probes are optional. Dia.5mm probe can provide

a faster suction speed due to over-thin thickness of the PVC material.

. Power from air compressor, safe and easy operation.

SPECIFICATIONS
Tank capacity (liter/US gallon)	65/17.1
Air Inlet Pressure (bar/psi)	6~8/87~116
Air inlet Connection (inch)	1/4
Vacuum Degree (bra)	-1~0
Air Pressure for Oil Discharge (bar/psi)	0.7~1/10~15
Oil Temperature Range (℃)	40~60
Suction Speed @ Probe dia. 8& Oil 60℃(Liter/m/ US Gallon/m)	6.5/1.72
Suction Hose (dia.@length)	Dia.19*1.5m
Draining Hose (dia.@length)	Dia.19*1.5m
Collection Bowl Capacity(liter/US gallon)	16/4.2
Collection Bowl Diameter (mm)	/
Maximum Height (mm)	/
Minimum Height (mm)	/
Optional Extension Funnel Diameter (mm)	/
N.W./G.W. (kgs)	18.5/21
Dimension (mm)	470440940
