HICHIP 2015 NEW Products 720P Full HD CCTV Box Camera,Onvif Wireless IP Camera
- 10000 Piece / Pieces per Month
- Shenzhen
- Credit Card
- 7 inch TFT Monitor DIGITAL Wireless Farm Cctv Systems
- 7 inch TFT Monitor DIGITAL Wireless New Backup Camera Kit with 2.4GHz digital signal
- 7 inch TFT Monitor Digital Reversing Camera System with 2.4GHz digital signal
- 7 inch TFT Monitor Wireless Back Up Systems with 2.4GHz digital signal
- Car Camera Wireless Transmitter System For Bus
- 7inch digital 2.4g wireless surveillance camera system For Bus
Product Details
Place of Origin: | China | Brand Name: | HICHIP/OEM | Model Number: | HX4001SW-WDR |
Type: | IP Camera | Style: | Box Camera | Technology: | NetWork |
Sensor: | Other, 1/2.7" 1.0 Megapixel WDR low illumination progressive CMOS sensor | Special Features: | Other, Wireless 720P Full HD Camera IP with WDR Function |
Product Description
HICHIP 2015 NEW Products 720P Full HD CCTV Box Camera,Onvif Wireless IP Camera
Features:
- 1/2.7" 1.0 Megapixel WDR low illumination progressive CMOS sensor
- H.264 three streams compression
- Resolution: 720P(1280*720), 25fps (PAL)/30fps (NTSC)
- 1CH Audio input (G.711/G.726), Two way voice talkback
- 1CH Alarm input, 1CH Alarm output
- one RS485 port, one RJ45 10/100M Ethernet port
- Support Mobile phone View
- Support SD Card record and capture; support motion detection, Email, FTP
- Support ONVIF2.0
- built-in 802.11b/g/n wireless network module
Technical Parameters:
Model | HX4001S-WDR |
operating system | embedded Linux |
main chipset | Hi3518 |
video compression | H.264 Main profile and Baseline profile adjustable |
Audio compression | G.726/G.711 |
sensor | 1/2.7” 1.0 megapixel progressive CMOS sensor |
video parameter | Brightness, Contrast, Saturation, Shutter, Flip, Mirror are adjustable |
CMOS performance | Support Auto White Balance(AWB), Auto Gain Control(AGC), Auto Backlight compensation(BLC), and so on |
Minimum illumination | 0.01Lux |
WDR range | 120dB |
Lens | 4-9mm |
video resolution | first stream: 720P(1280*720) and Q720P(640*352) are optional |
second stream: Q720(640*352) and QQ720P(320*176) are optional | |
third stream: QQ720P (320*176) | |
JPEG code rate: Q720P(640*352) and QQ720P(320*176) are optional (for mobile phone viewing) | |
video frame rate | first stream: PAL: 1-25fps NTSC: 1-30fps |
second stream: PAL: 1-25fps NTSC: 1-30fps | |
third stream: PAL: 1-25fps NTSC: 1-30fps | |
video compression Bitrate | 32Kbits/s – 6Mbits/s adjustable |
Audio Input | Volume 1-100 adjustable; default is 31 for microphone input; default is 15 for linear input |
Audio Output | Volume 1-100 adjustable; default is 79 |
Audio format | G.726/G.711, default is G.726 |
Alarm I/O | 1CH Input(normally open/normally close adjustable), 1CH Output, 120V AC 2A / 24V DC 2A |
Motion Detection | 4 independent area can be set (sensitivity 1-100 adjustable) |
Alarm linkage | sending pictures to named mailbox; upload pictures and video to FTP server; pictures and videos to SD Card |
control port | 1CH RS485 |
Network protocal | TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP, and so on |
Access protocal | support ONVIF, and support authority verify(defalut close authority verify) |
storage | Max 32G SD Card, supporting Timer record storage |
network port | 10Base-T/100Base-TX Ethernet port |
Wifi 802.11b/g/n wireless network (optional) | |
power supply | DC 12V 1A; support POE (optional) |
Power consumption | 3W |
Size | 115mmx64mmx58mm |
Operating temperature | -20 ~ +70 ℃ |
Operating humidity | 10 ~ 95%RH |
Super client:
Alarm:
Package:
Motion detection:
Support Multi platform viewing:
Payment & shipping:
Our Service:
OEM and ODM service are acceptable.
Welcome your trial order!
Contact Us
- Shenzhen Hichip Vision Technology Co., Ltd.
- Contact nameLily Liao
- Phone86-0755-61617830
- AddressRoom 2105-2104, East Building of Yihai Plaza, Chuangye Road, Nanshan District Shenzhen,Guangdong
