Specifications
1.Thermal conductive tape2.LED thermal tape
3.Standard size:500mm*50M,500mm*25M
4.Industry direct price
Double Sided Glass Fabric Thermally Conductive Adhesive Tape
We are a professional professional manufacturers of thermal interface materials in China.
HCT series is a kind of Thermally conductive, fiberglass reinforced pressure sensitive adhesive tape applied in the bond between heat sink and other power consumption semiconductor, the adhesive is in the nature of strong
bonding strength and low thermal resistance, which can replace thermal silicon grease and mechanical fixation
effectively .
Features & benefits:
-High acrylic adhesive tape for pressure sensitive of various surfaces
-High-performance, thermally conductivity acrylic adhesive
Typical applications:
-Make the heat sink fixed to the encapsulated chip
-Make the radiator fixed to the power supply circuit board or the vehicle control circuit board
-Efficient thermal conductive acrylic adhesive
-Can replace the fixed mode of hot melt adhesive, screw and buckle
Physical properties:
Test Item |
Test method |
Unit |
Test Value |
Reinforcement carrier |
- |
- |
Fiberglass |
Color |
Visual |
- |
Blue |
Thickness |
ASM D374 |
mm |
0.1 to 0.5 |
Temperature Resistance |
- |
°C |
180 |
Adhesion strength |
ASTM D412 |
Kg/inch2 |
1.2 |
Breakdown voltage |
ASTM D149 |
KV/mm |
3 to 7 |
Initial adhesion |
ASTM D1002 |
kg/inch |
0.6 to 1.5 |
Thermal conductivity |
ASTM D5470 |
W/m-k |
1.5 |
Continuous use temp |
EN 344 |
°C |
-40 to +180 |
Configurations available: 500mm*50M, specific size could be provided according to your requirements.
Why choose KUAYUE'''S thermal interface material?
1.Only thermal conductivity material we produced, so we are more professional.
2.We have a series of advanced equipments,look the one piece of the following pictures.
3. We are have our Lab Room test and directly control the quliaty of the products.
Thermal Conductivity Tester for test the Thermal conductivity
Constant Temperature Oven for test the Continuous use Temperature
4. Many of our thermal interface material has recieved the SGS,UL certification.
