Help CenterBeam Splitter Cubes
Related Products
Cube Beamsplitters offer a range of reflection/transmission ratios. It consists of two right- angle prisms. An interference coating has been applied to the hypotenuse surface of one of the prisms to provide the designated reflection/transmission ratio. Absorption loss to the coating is minimal.
Application:
Beamsplitters are also ideal for fluorescence applications, optical interferometry, or life science or semiconductor instrumentation. Light can be split by percentage of overall intensity, wavelength, or polarization state.
Parameters
Material |
Bk7,UV Fused Silica, Optical Glass |
Dimension Tolerance |
± 0.1mm |
Dimension |
0.5mm-200mm |
Surface Quality |
60/40 |
Flatness |
<λ/4@633nm |
Beam Deviation |
< 3 arc minutes |
Extinction Ratio |
Tp / Ts > 100: 1 @ 632.80nm |
Splitting Ratio |
5:5 |
T/R |
Tp > 95% @ 632.8nm Rs > 99.5% @ 632.8nm |
T/R Tol |
+/-5% |
Wavelength |
450-650nm |
Incident Angle |
0 degreee |
Angle Tolerance |
+/- 3 arc minutes |
Clear Aperture |
90% |
Bevel |
0.3mm x 45 deg |
Design wavelength |
632.8nm |
♣ Advanced processing equipment and complete production system are ensure that we can effectively control every aspect of the product process to ensure product quality, and reduce losses and reduce costs !
¦
♣ Advanced testing equipment and methods are important guarantee for the production of high-precision products.
¦
♣ We have participated in the national exhibitions,including optical fair in Shenzhen and Shanghai, Munich optical fair,and establish the business with many foreign customers.
¦
♣ Worldhawk can provide a variety of types of optical products,including ball lens, powell lens, axicon lens, mirrors, windows and aspherical lens, We have ability to process high-precision micro lens and can customized various of the sapphire products according to the customer.
¦
1+
Q: What's the way of shipping and cost?
A:
(1) We accept DHL, Fedex, TNT, UPS, EMS, SF and etc.
(2) If you have your own express number, it's great.
If not, we could assist you to deliver. Freight=USD35.0(the first weight) + USD12.0/kg
2+
Q: How to pay?
A: T/T, Paypal, West Union, MoneyGram, Secure payment and Assurance payment on Alibaba and etc..
3+
Q: What's your MOQ?
A:
(1) For inventory, the MOQ is 5pcs.
(2) For customized products, the MOQ is 10pcs-20pcs.
4+
Q: What's the deliver time?
A:
(1) For the standard products such as ball lens, powell lens and collimator lens:
For inventory: the delivery is 5 workdays after you place the order.
For customized products: the delivery is 2 or 3 workweeks after you place the order.
(2) For the off-standard products, the delivery is 4 or 6 workweeks after you place the order.
5+
Q: Do you have standard products?
A: Our standard products includes optical ball lens, optical half ball lens and powell lens.
6+
Q: Can I customize the products based on my need?
A: Yes, we can customize the material, specifications and optical coating for your optical components based on your needs.
7+
Q: Do you have inspection report for material?
A: We can supply ROHS report for our products.
8+
Q: How to ensure the safety of payment?
A: Worldhawk is the gold supplier for 5 years and supports Alibaba Trade Assurance.
♣ We pay attention to every details of the package , cleaning, anti-static , shock treatment . According to the quantity and shape of the product , we will take a different packaging process !
¦
Packaging Material
Inner Packaging Forms
Safe Delivery
¦
Logistics
In order to make the goods safe fast accurate to your hands, we generally recommend that you choose the international logistics company!
¦
