Help CenterVacuum Metallizing Machine for Metallic Yarn Metallic Yarn Vacuum Metallizing Machine
Related Products
-
Aluminum Vacuum Coating MachineUS$ 150,000 - 250,000MOQ: 1 Set -
Vacuum Metallizing Machine for CPP Film CPP Film Vacuum Metallizing MachineNegotiableMOQ: 1 Set
-
Roll to Roll Vacuum Metallizing MachineUS$ 300,000 - 400,000MOQ: 1 Set
-
Vacuum Metallizing Machine for Hologram Hologram Metallizing MachineUS$ 200,000 - 300,000MOQ: 1 Set
-
Roll Vacuum Coater for Bopet Film Bopet Film Vacuum CoaterUS$ 300,000 - 400,000MOQ: 1 Set
The metallic yarn vacuum metallizing machine can steam-plate many kind of materials such as PET, OPP, PVC, CPP, anti-counterfeit materials, hot stamping foil, gold and silver thread and surface decoration plastic film. It also can plate various of label, bottle label, brand, materials of warm-keeping and beam-reflecting papers, various of medium materials.
Data list of metallic yarn vacuum metallizing machine ( Model No.:H1600-16)
Name |
Specification |
diameter of vacuum chamber |
φ1600mm×length 2000mm |
Film width: |
1600mm |
rolling diameter |
680mm |
winding speed |
200m/min 500m/min |
Al-wire feeding speed |
0-5m/min,Aluminum wire φ250mm |
Way of Al-wire feeding |
Al-wire feeding by adjustment in-phase |
Evaporation transformer |
16units,each unit for power 12 kw and output is 10v and the current is 1200A |
Quantity of evaporation boats |
16pieces,each piece for power 12kw,constant voltage and automatic thermal retardation adjustment ,boat size:30X11X110mm |
General chilling unit |
One set (Handun,Shanghai) |
Working power |
About 200kw |
1.Two engineers available to service machinary overseas.
2. It's 12 months warranty.
3.We are a family company and not a partner company,so we can supply after-sales service for long term.
1. Certificate: CE
2. Sold more than 20 machines to India,Turkey,Iran,Vietnam,Bangladesh,North Korea.
Sales assistant: Ms Sophia Chen
Mobile: +86-13902736527
1. Certificate: CE
2. Sold more than 20 machines to India,Turkey,Iran,Vietnam,Bangladesh,North Korea.
Sales assistant: Ms Sophia Chen
Mobile: +86-13902736527
