Place of Origin Jiangsu, China
Shape Powder
Material Alumina Block
SiO2 Content (%) 50%~65%
Al2O3 Content (%) 55-90
MgO Content (%) 0.8-1.2
CaO Content (%) 0.01
CrO Content (%) 0.1~0.3%
SiC Content (%) 0.1~1.4%
Brand Name TY

[TY]High Performance Refractory Castables of Blast Furnace





Product Description

        The refractories of blast furnace are mainly about unshaped refratories. The products contain castable, ramming mass, plastics-forming product, prefabricated parts, and so on. The high working property of products can satisfy various blast furnaces.



Specifications



Types ASC-1 ASC-2 CTG ASC-3 ASC-4 AM90T SA170 GL150
Material

Alumina

 silicon

 carbide

Alumina

 silicon

 carbide

Alumina

 silicon

 carbide

Alumina

 silicon

 carbide

Alumina

 silicon

 carbide

Corundum

 magenesia

Alumina

 silicon

 carbide

High

 alumina

Fracture

 Strength MPa

 110℃*24h ≥3 ≥3 ≥4 ≥4 ≥4 ≥4 ≥6 ≥4
1450℃*3h ≥6 ≥5 —— ≥8 ≥6

≥10

(1500℃)

 ≥10

≥10

  (1500℃)

Compressive

 Strength MPa

 110℃*24h ≥20 ≥20 ≥20 ≥30 ≥20 ≥25 ≥45 ≥30
1450℃*3h ≥35 ≥30 ≥40 ≥60 ≥50 ≥50(1500℃) ≥65

≥70

  (1500℃)

Coefficient of

 linear

 expansion %

 1450℃*3h ±0.5 ±0.5 ±0.5 —0.2±0.5 ±0.3

0-2.0

   (1500℃)

 ±0.5

0-1.5

 (1500℃)
Density g/cm3 110℃*24h ≥2.85 ≥2.75 ≥2.65 ≥2.80 ≥2.55 ≥2.90 ≥2.85 ≥2.35
1450℃*3h ≥2.80 ≥2.70 —— ≥2.75 ≥2.50 —— ≥2.80 ——

Chemical

 composition %

 Al2O3 ≥65 ≥50 ≥65 ≥70 ≥55 ≥88 ≥60 ≥55
SiC ≥10 ≥30 ≥10 ≥8 ≥12 —— ≥12 ——
C ≥2 ≥2 ≥3 —— ≥2 —— —— ——
Applicatons

Main trough

 metal line

Main trough

 slag line

Main

 trough for

 furnaces

 Iron runner Slag runner

De-sitilting

 runner for

 blast furnaces

Cover for

 main trough

Trough

 cover for

 blast

 furnaces
