Specifications
Plastic injection molding machine manufacturer1. PET preform, PE caps molding machine
2. Output 2000pcs,4000pcs,6000pcs
Plastic injection molding machine manufacturer
PRESENTATION OF PRODUCTS WITH ADVANTADGES
Products Range of Plastic injection molding machine manufacturer : 60 Ton------4000 Ton
lEnergy Saving Machines With Servo System
lPVC Special
lPET Special
lHigh Speed
lFull Electric
CREATS VALUES of Plastic injection molding machine manufacturer
lBIGGER PARAMETER—SAVE INVESTMENT
lPOWER SAVING—SAVE ENERGY, 50—80%
lHIGH PERFORMANCE—EUROPEAN STANDARD
Parameters of Plastic injection molding machine manufacturer
Specification Table |
CY2680 |
|
|||
A |
B |
C |
|||
Injection Unit |
Screw Diameter (mm) |
50 |
55 |
60 |
|
Screw L/D Ratio (L/D) |
23.1 |
21 |
19.3 |
||
Shot Size(Theoretical) (cm³) |
580 |
703 |
828 |
||
Injection Weight ( g) |
527 |
640 |
754 |
||
Injection Rate (g/s) |
193 |
229 |
259 |
||
Plasticizing Capacity (g/s) |
28.9 |
31.6 |
34.7 |
||
Injection Pressure (Mpa) |
205 |
169 |
142 |
||
Screw Speed (rpm) |
180 |
|
|||
|
Clamping Unit
|
Clamping Force (KN) |
2680 |
|
||
Toggle Stroke ( mm) |
540 |
||||
Space Between Tie-Bars (mm) |
580*580 |
|
|||
Max.Mould Height (mm) |
600 |
||||
Min. Mould Height (mm) |
230 |
||||
Ejector Stroke (mm) |
145 |
||||
Ejector Tonnage (KN) |
71 |
||||
|
Other
|
Max.Pump Pressure (Mpa) |
16 |
|||
Pump Motor Power (KW) |
22 |
||||
Heating Power (KW) |
16 |
||||
Machine Dimensions(LxWxH) (m) |
5.81*1.8*2.1 |
||||
Machine Weight(Approximate ) (t ) |
8.1 |
||||
