Touch payment kiosk as ATM machine
| LCD Panel | Type of Display |
TFT-LCD |
Panel Size |
15, 17, 19 inch |
|
Display Ratio |
4:3 or 16:9 |
|
| Response Time | 5ms | |
| Windows OS | CPU |
Intel® i3-3220 |
Graphics |
Intel HD Graphic 2500 |
|
| RAM | DDR3, 4GB |
|
| HDD | 500GB | |
| WIFI | WIFI module+WIFI Antenna | |
| Touchtech | Option 1 | Infrared 6 touch points |
| Option 2 | Capacitive 10 touch points | |
|
Main components
|
Card Reader | Card Type: Magcard, IC Card, RF Card, Mifare Card, UL Card |
Interface: RS232/USB | ||
Card Entry Method: Signal of Magnetic, Optoelectronic and rear card | ||
|
Encrypted Pin Pad |
Key Life Span: 2,000,000 cycles |
|
Key Force: 2-3N | ||
Key Trip: >2.5mm | ||
Protection Level: IP65 | ||
Bill Acceptor |
Brand: Cash Code/ MEI/ ITL/ICT |
|
Validation Rate: High than 96% | ||
Capacity: 600notes~1500notes | ||
|
Thermal Printer |
Auto-cutter: Included |
|
Width of Paper: 50mm/80mm/112mm | ||
Printing Speed: 150mm/s | ||
Buffer of Data: 4Kb | ||
Interface: RS232/USB | ||
| Optional component | A4 Printer, Coin acceptor, UPS, Web-camera etc |
|
| Main Hardware | Shell Material |
Tempered glass+4.5 mm thickness Metal Back Shell |
| Suface |
Metal case with powder burning;Tempered glass to protect LCD panel |
|
| Speaker |
2*10W built-in stereo speakers |
|
Heat Dispersion |
Built-in DC fans |
|
| Power | Standby |
≤3W |
Working |
30W-180W |
|
| Power supply | AC 110V - 240V, 50/60HZ | |
| Storage Temperature | -7℃ to 65℃ | |
| Normal Working Temperature | -5℃ to 65℃ |
Multi-pay methods: Accepting cash, coin, debit cards, credit cards, checks.
7x24 hours running; Save labor cost and employee time of your organization
Ticketing & payment secure and card issuing solution
User-friendly; easy to maintenance
| Business Product Promotional display |
supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels,restaurants, travel agencies, pharmacy |
| Financial Organizations | Banks, negotiable securities, funds, insurance companies, pawnshops; Non-profit Organizations: Telecommunications, post offices, hospital, schools |
| Public Places |
subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums,convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers |
| Entertainments |
Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course |
Fantasy View, one of the world’s leading digital commercial display providers. Design and produce high-quality LCD advertising player,, touch touch screen information kiosk ,digital signage , card dispenser kiosk , self-service kiosk, touch screen information kiosk terminal,kiosk , self service digital signage terminal,note accepter lobby kiosk,dual screen kiosk, mall kiosk, interactive information kiosk, kiosk with touch screen , Gaming kiosk, Health care kiosk,airport kiosk,ticket vending kiosk,wall mounted kiosk, interactive kiosk, bill payment kiosk,card reader touch screen , dual screen kiosk,photo kiosk, information inquiry kiosk, and multimedia information kiosk. Fantasy View has wall mounted kiosk and frees tanding kiosk,dual screen kiosk, single screen kiosk,double side screen kiosk, with the touch screen size ranges from 15” to 98”.
We purchases its raw materials from the top producers in the world and conducts quality control on each and every material before storing it in the warehouse Not a single screw goes unchecked in this tightly regulated process. The original panels all are from Samsung and LG etc.
In the digital signage industry, Fantasy View is one of the first few companies that passed the international standards of CE, FCC, UL, CCC, IP65&IP66.
Our company's philosophy is: customer first, quality is the life, integrity management, innovation is the company's blood.We have very excellent product designers and engineers for quality escort and provide 24-hour after-sales service
Our factory is located in A Building 2 floor,Ground pine eco-technology Park,Jie Jia Bao Road 9,shiyan town,street community in paddy field,Bao an District,Shenzhen,China.You are very welcome to visit our factory.
1.Q:Are you a factory or trading company?
A:We are a OEM/ODM factory
2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in A Building 2 floor,Ground pine eco-technology Park,Jie Bao Road 9,shiyan town,street community in paddy field,Bao an District,Shenzhen,China.
3.Q:Can I get some sample?
A:Sample order is welcome.
Price would be negotiated bassed on bigger quantity
4.Q:How does your factory do regarding quality control?
A:Our company's philosophy is: customer first, quality is the life, integrity management, innovation is the company's blood.We have very excellent product designers and engineers for quality escort and provide 24-hour after-sales service.Our factory has gained CE/CCC/FCC/ROHS/IP65&IP66.And welcome to visit our factory.
5.Q:What is your after-sale service?
A:We offer 100% guarantee on our product.
6.Q:When will you make the delivery?
A:We can make the delivery within 3-15 working days according to the size of your order.
If you want to know more about our products and company,welcome to contact us any time.
Packaging Details: Plastic film+EPE+Standard carton+Export wooden
Delivery Detail: 3days
