Specifications
Cctv Camera1.SONY CCD
2.420/480/540/600/700TVL for optional
3.Water-proof IP67
4.FCC RoHS CE
Water-proof IR Cctv Camera 600TVL Video Camera for car/ bus/ Truck Security
Specification
CCD sensor |
1/3"SONY CCD |
1/3"SONY CCD |
1/3"SONY CCD |
1/3"SONY CCD |
|
pixel (H×V) |
PAL:795×596 NTSC:811×508 |
PAL:752×582 NTSC:768×494 |
PAL:752×582 NTSC:720×480 |
PAL:500×582 NTSC:510×492 |
|
Horizontal resolution |
650TVL |
540TVL |
480TVL |
420TVL |
|
signal system |
PAL / NTSC |
||||
Horizontal synchronous frequency |
PAL:15.625KHZ / NTSC:15.734KHZ |
||||
clock frequency MHZ |
PAL:19.3125 / NISC:19.0699 |
||||
scanning system |
2:1 interlaced scanning |
||||
lowest illumination |
0LUX(IR led open) |
||||
method of synchronization |
internal synchronization |
||||
S/N |
48 dB |
||||
electronic shutter |
PAL:1/50-1/100,000sec;NTSC:1/60-1/100,000 |
||||
Gamma characteristics |
0.45 |
||||
video output |
1 Vpp,75 Ohms |
||||
AGC |
automatic |
||||
power supply |
12V DC (+/-10%) |
||||
electricity current |
300mA |
||||
working temperature |
-10-45°C |
||||
Key Features
1.SONY/SHARP CCD (optional)
2.420TVL-600VL (definition are optional)
3.Optically controlled design; auto exposure to control on/off switch of IR led
4.High-efficient IR tube
5.Auto AGC; auto white balance; BLC
6.IR distance 10/20M
7.Standard fixed lens: 3.6mm/6mm
Certification CE FCC ROHS
Applications of Cameras
Our cameras are widely used in bus, car, taxi, dangerous cargo truck, police car, van, Train, ship, home security etc.
Packing Detail
1. Brand Box with Our Logo Richmor.
2. Neutral Box.
3. Your Logo is also Welcomed.
Quality Control
All our products must be pre-tested by professional QC before shipping!
2 years warranty from the date you purchase, Lifelong warranty.
Our devices must be aged more than 48 hours before sending to customers.
Cinderella from Richmor is warmly wleome you to visit our factory!
We'd like to be your No.1 Professional Guide for DVRs & Cameras in China!
