170 Degree Mini Waterproof Car Reversing Camera Mini Hd 808 Car Key Camera

Specifications

Mini Hd 808 Car Key Camera
1.SONY CCD
2.420/480/540/600/700TVL for optional
3.Water-proof IP67
4.FCC RoHS CE

170 Degree Mini Waterproof Car Reversing Camera Mini Hd 808 Car Key Camera



Specification

CCD sensor	1/3"SONY CCD		1/3"SONY CCD	1/3"SONY CCD	1/3"SONY CCD
pixel (H×V)	PAL:795×596 NTSC:811×508		PAL:752×582 NTSC:768×494	PAL:752×582 NTSC:720×480	PAL:500×582 NTSC:510×492
Horizontal resolution	650TVL		540TVL	480TVL	420TVL
signal system		PAL / NTSC
Horizontal synchronous   frequency		PAL:15.625KHZ / NTSC:15.734KHZ
clock frequency MHZ		PAL:19.3125 / NISC:19.0699
scanning system		2:1 interlaced scanning
lowest illumination		0LUX(IR led open)
method of synchronization		internal synchronization
S/N		48 dB
electronic shutter		PAL:1/50-1/100,000sec;NTSC:1/60-1/100,000
Gamma characteristics		0.45
video output		1 Vpp,75 Ohms
AGC		automatic
power supply		12V DC (+/-10%)
electricity current		300mA
working temperature		-10-45°C



 Key Features



1.SONY/SHARP CCD (optional)



2.420TVL-600VL (definition are optional)



3.Optically controlled design; auto exposure to control on/off switch of IR led



4.High-efficient IR tube



5.Auto AGC; auto white balance; BLC



6.IR distance 10/20M



7.Standard fixed lens: 3.6mm/6mm







 Certification



Applications of Cameras



Our cameras are widely used in bus, car, taxi, dangerous cargo truck, police car, van, Train, ship, home security etc.





Packing Detail



1. Brand Box with Our Logo Richmor.

2. Neutral Box.

3. Your Logo is also Welcomed.



 Factory Overview





Quality Control

1) All our products must be 100% pre-tested before shipping by our professional QC Team

2) Items have 18 months warranty since the date receving the goods.

3) Aging time 48 hours to ensure stable quality

4) Life time tech support
