Specifications
Vehicle Car Dvr Camera1.SONY CCD
2.420/480/540/600/700TVL for optional
3.Water-proof IP67
4.FCC RoHS CE
Backup Car Rearview Camera System for Citroen C4 Vehicle Car Dvr Camera
Specification
CCD sensor |
1/3"SONY CCD |
1/3"SONY CCD |
1/3"SONY CCD |
1/3"SONY CCD |
|
pixel (H×V) |
PAL:795×596 NTSC:811×508 |
PAL:752×582 NTSC:768×494 |
PAL:752×582 NTSC:720×480 |
PAL:500×582 NTSC:510×492 |
|
Horizontal resolution |
650TVL |
540TVL |
480TVL |
420TVL |
|
signal system |
PAL / NTSC |
||||
Horizontal synchronous frequency |
PAL:15.625KHZ / NTSC:15.734KHZ |
||||
clock frequency MHZ |
PAL:19.3125 / NISC:19.0699 |
||||
scanning system |
2:1 interlaced scanning |
||||
lowest illumination |
0LUX(IR led open) |
||||
method of synchronization |
internal synchronization |
||||
S/N |
48 dB |
||||
electronic shutter |
PAL:1/50-1/100,000sec;NTSC:1/60-1/100,000 |
||||
Gamma characteristics |
0.45 |
||||
video output |
1 Vpp,75 Ohms |
||||
AGC |
automatic |
||||
power supply |
12V DC (+/-10%) |
||||
electricity current |
300mA |
||||
working temperature |
-10-45°C |
||||
Key Features
1.SONY/SHARP CCD (optional)
2.420TVL-600VL (definition are optional)
3.Optically controlled design; auto exposure to control on/off switch of IR led
4.High-efficient IR tube
5.Auto AGC; auto white balance; BLC
6.IR distance 10/20M
7.Standard fixed lens: 3.6mm/6mm
Certification
Applications of Cameras
Our cameras are widely used in bus, car, taxi, dangerous cargo truck, police car, van, Train, ship, home security etc.
Packing Detail
1. Brand Box with Our Logo Richmor.
2. Neutral Box.
3. Your Logo is also Welcomed.
Factory Overview
Quality Control
1) All our products must be 100% pre-tested before shipping by our professional QC Team
2) Items have 18 months warranty since the date receving the goods.
3) Aging time 48 hours to ensure stable quality
4) Life time tech support
