mobile ip dvr with gps tracking & usb slot
Mobile DVR overview:
mobile ip dvr with gps tracking & usb slot
• H.264 video compression
• 1*SD Card (Max 64GB)
• 1* USB slot
• Power-off protection and redundant power supply
• Built-in 3G (WCDMA/cdma2000/TD-SCDMA) module
• Built in GPS module
• Supports PTZ control
Specification
mobile ip dvr with gps tracking & usb slot
* Standard H.264 video compression, supports dual stream network transmission
* Supports pentaplex operation: preview, record, playback, backup, network transmission
* Support max 64GB SD card
* Support alarm pre-recording & motion detection
* Supports real-time remote view through 3G
* GPS information embedded in stream (optional), support electronics fence and historical track playback
* Supports time-lapse recording after the car is powered off
* Supports recording and displaying the license plate number
* Supports SD card overwritten by days
* With digital zoom capabilities when previewing the video
* With password protection function
* Supports PTZ control
* Supports transmitting audio via network
* Supports backup and upgrade with SD card
* Stable aluminum alloy structure with shock absorber
* Self recovery after power reconnected
mobile ip dvr with gps tracking & usb slot
Product Photos
Parameters
Items |
Device parameters |
Performance index |
Name |
Product Name |
4 Channel Mobile DVR (SD Storage) |
System |
Operation System |
Linux |
Operation Interface |
Graphical Interfaces, Chinese/English optional |
|
File System |
Proprietary Format |
|
System Privileges |
User Password |
|
Video |
Video Input |
4ch SDI Independent Input: 1.0Vp-p,75Ω.Both B&W and Color Cameras |
Video Output |
1 Channel PAL/NTSC Output, 1.0Vp-p,75Ω, Composite Video Signal |
|
Video Display |
1 Or 4 Screen Display |
|
Video Standard |
PAL:25frames/Sec;NTSC:30frames/Sec |
|
System Resources |
PAL:100 Frames; NTSC:120 Frames |
|
Audio |
Audio Input |
Two Channels Independent Input 500Ω |
Audio Output |
1 Channel(4 Channels Can Be Convert Freely) |
|
Basic Output Level |
1.0—2.2V |
|
Distortion Plus Noise |
≤-30dB |
|
Recording Mode |
Sound And Image Synchronization |
|
Audio Compression |
ADPCM |
|
Alarm |
Alarm in |
3 Channels Independent Input. High Voltage Trigger |
Alarm out |
1 Channels Independent output |
|
Move Detect |
available |
|
USB Interface |
Host Access |
Can Expand One For USB Disk Backup |
|
Network Interface |
3G |
Can Expand One WCDMA or CDMA2000 Module Inside |
GPS Interface |
GPS |
Can Expand GPS Module inside |
Extend Interface |
Intercom |
Can Expand Intercom Module Inside |
Others |
Power Consumption |
DC8-36V 5% ≤10W |
Working Temperature |
-20°C ~ +85°C ≤80% |
|
Clock |
Built-In Clock, Calendar |
|
Packaging |
Product Size |
113(L)*104(W)*40(H)mm |
Product Net Weight |
0.60kg |
Payment terms:
T/T, Western Union, MoneyGram, Paypal
Shipping ways:
DHL, UPS, Fedex, EMS
Delivery time:
Within 3-5 working days after confirm the payment
Our certificates:
Case for reference
About us:
Any enquiry on Mobile DVR,warmly welcome to connect with us.
Cell phone:+86 18929318475 Skype: rcmcctvsales7
Contact Representative: Vicky Chan
